Curtis Tube Fittings, located in Manila, Philippines, stands out as a top-notch manufacturer and supplier of high-quality fluid control solutions, with a special focus on 904L Ball Valves. These valves are celebrated for their remarkable corrosion resistance and durability, making them reliable performers even in the toughest industrial settings. At Curtis Tube Fittings, they blend precision engineering with advanced manufacturing techniques and strict quality standards to produce valves that guarantee leak-free operation and long-lasting performance. Their 904L Ball Valves find extensive use in the chemical, petrochemical, oil and gas, and marine sectors, offering excellent flow control, operational safety, and resilience against harsh corrosive environments.
Constructed primarily from 904L stainless steel, these ball valves are a high-alloy austenitic stainless steel known for its outstanding resistance to corrosion, particularly in the presence of strong acids and chloride-rich conditions. The valves are designed with a precisely machined ball and seat, ensuring smooth operation, tight sealing, and minimal leakage. They boast high mechanical strength, durability under high-pressure and high-temperature scenarios, and exceptional resistance to pitting, crevice corrosion, and stress corrosion cracking. These features make 904L Ball Valves perfect for demanding applications that require longevity, reliability, and resistance to aggressive chemicals or saline environments.
| STANDARD | API 600/BS1414, API 598/BS EN 12266-1, ASME B 16.10, ASME B 16.5, ASME B 16.25, ASME B 16.34 |
| VALVE SIZE | 1/8″ TO 2″ / 6 MM TO 50 MM |
| THREAD | NPT, BSPP, BSPT, JIC, METRIC, UNF |
| CONNECTION | THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE |
| FUNCTION | 2 WAY, 3 WAY, 4 WAY, 5 WAY, |
| PRESSURE RATING | 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI |
| SEAL RING MATERIAL | PTFE, PVDF, DELRIN, PEEK, GRAPHITE |
| STANDARD | ISO , DIN , ANSI , API , ASME , AWWA , MSS , |
| MEDIA | HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL |
| MEDIA TEMPERATURE | (-120* C TO 500*C )RANGE AS PER PRESSURE |
| BODY TYPE | BAR STOCK |
| BRAND NAME | TU-LOK |
| PACKING DETAILS | BOX PACKING, WOODEN PALLET |
| EQUIVALENT BRANDS | SWAGELOK, PARKER, DK-LOK, HAMLET, OLIVER VALVES, HOKE |
| APPLICATION | MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES , POWER GENERATING PLANT , STEEL MANUFACTURING PLANT , MINING INDUSTRIES , CHEMICAL PROCESSING MACHINES , PIPING LINE , PAINT INDUSTRIES , TRUCKS AND TRAILERS , AUTOMATION , AGRICULTURE MACHINES , AEROSPACE & DEFENCE EQUIPMENTS, |
|
Tensile Strength (MPa) min |
Yield Strength 0.2% Proof (MPa) min |
Elongation (% in 50mm) min |
Hardness
Rockwell B (HR B) |
Hardness
Brinell (HB) |
|---|---|---|---|---|
|
490 |
220 |
36 |
70-90 typical |
150 |
| C | Mn | Si | P | S | Cr | Mo | Ni | Cu |
|---|---|---|---|---|---|---|---|---|
| 0.02 Max | 2.0 Max | 1.0 Max | 0.045 Max | 0.035 Max | 19.0 Min 23.0 Max | 4.0 Min 5.0 Max | 23.0 Min 28.0 Max | 1.0 Min 2.0 Max |
Venton Tube Fittings is the premier supplier, manufacturer and exporter of (904L Ball Valve) in Manila, Philippines. Our strategic manufacturing units placed in the Philippines allow us to supply high-quality solutions customized to your needs. We value Efficiency and Excellence. Ensuring that our products meet the highest industry standards. Maintaining a well-stocked inventory we are always ready to ship orders in time and reliably. Our dedication to customer satisfaction compels us to deliver strong and reliable solutions for a wide range of industrial uses.
Venton Tube Fittings is a trusted and exporter of top-quality(904L Ball Valve) Philippines. Our products are used widely across diverse industries, proving our commitment to excellence and customer satisfaction. Our unique finishing processes set us apart in the metal istockist ndustry. We assure premier product quality and reliability. Our dedication to innovation and precision, enables us to provide to the evolving needs of our clients while maintaining the highest standards of service.
Contact us to get a quick quote for your requirement.
You’ll find 904L Ball Valves widely used in industries that need dependable corrosion-resistant flow control. In chemical and petrochemical facilities, they safely and efficiently handle highly corrosive fluids. They are crucial in oil and gas pipelines, offshore platforms, and marine applications where exposure to saltwater and harsh chemicals is common. Moreover, they play a vital role in pharmaceuticals, water treatment, and desalination plants, where durability and leak-free operation are essential. The combination of high corrosion resistance, mechanical strength, and precision makes 904L Ball Valves a must-have for industries that demand the best.
Please feel free to contact us if you need any further information or for enquiry.
