Curtis Tube Fittings, Manila, Philippines, is a renowned producer and distributor of top-quality industrial fittings and valves with a reputation for providing precision-engineered solutions for fluid and gas control. Operating in industries such as aerospace, chemical processing, and marine, the company prioritizes durability and customer satisfaction. Among their high-end products is the Titanium Ball Valve, which is produced from Titanium Grade 2 and Grade 5 (Ti-6Al-4V). This spherical-shaped valve offers superior corrosion resistance, light weight, and high strength, which makes it suitable for high-pressure applications in aerospace, marine, oil and gas, and chemical industries

Titanium Alloy 3 Way Ball Valve in Manila, Philippines, Titanium 4 Way Ball Valve Price in Davao City, Titanium 5 Way Ball Valve Supplier in Cebu City, Titanium High Pressure Ball Valve Price List in Puerto Princesa, Titanium Instrumentation Ball Valve Manufacturer in Manila, Titanium Alloy Compression Ball Valve in Baguio, Titanium Hydraulic Ball Valve Supplier in Cebu City, Titanium High Pressure Ball Valve Price List in Manila, Titanium 2 Way Ball Valve Price in Baguio

Titanium Ball Valve Specifications
Titanium Ball Valve Chemical Composition
Titanium Ball Valve Mechanical Properties
Titanium Ball Valve Equivalent
Top Titanium Ball Valve Manufacturing Company in Manila
Types of Titanium Ball Valve
Largest Manufacturer and Supplier of Titanium Ball Valve in Manila, Philippines
Titanium Ball Valves Uses
Visit Our Other Products

Titanium Ball Valves are generally constructed of Titanium Grade 2 (commercially pure titanium) and Titanium Grade 5 (Ti-6Al-4V). Grade 2 is 99% titanium, which has good corrosion resistance and average strength, and Grade 5 is 90% titanium, 6% aluminum, and 4% vanadium, which has increased strength and heat resistance. The valves possess tensile strength of 345 MPa (Grade 2) and 895 MPa (Grade 5) with densities of 4.51 g/cm³ and 4.43 g/cm³, respectively. Their density is low, melting point is high (1,660°C), and oxidation resistance is good, rendering them suitable for hard conditions.

Titanium Ball Valve Specifications

STANDARD	ASTM B367, API 600/BS1414, API 598/BS EN 12266-1, ASME B 16.10, ASME B 16.5, ASME B 16.25, ASME B 16.34
VALVE SIZE	1/8″ TO 2″ / 6 MM TO 50 MM
THREAD	NPT, BSPP, BSPT, JIC, METRIC, UNF
CONNECTION	THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE
FUNCTION	2 WAY, 3 WAY, 4 WAY, 5 WAY,
PRESSURE RATING	1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI
SEAL RING MATERIAL	PTFE, PVDF, DELRIN, PEEK, GRAPHITE
STANDARD	ISO , DIN , ANSI , API , ASME , AWWA , MSS ,
MEDIA	HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL
MEDIA TEMPERATURE	(-120* C TO 500*C )RANGE AS PER PRESSURE
BODY TYPE	BAR STOCK
PACKING DETAILS	BOX PACKING, WOODEN PALLET
APPLICATION	MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES , POWER GENERATING PLANT , STEEL MANUFACTURING PLANT , MINING INDUSTRIES , CHEMICAL PROCESSING MACHINES , PIPING LINE , PAINT INDUSTRIES , TRUCKS AND TRAILERS , AUTOMATION , AGRICULTURE MACHINES , AEROSPACE & DEFENCE EQUIPMENTS,

Titanium Ball Valve Chemical Composition

Grade	Ti	C	Fe	H	N	O	Al	V
Ti Grade2	99.2 min	0.1 max	0.3 max	0.015 max	0.03 max	0.25 max	–	–

Titanium Ball Valve Mechanical Properties

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Titanium Gr. 2	4.5 g/cm3	1665 °C (3030 °F)	Psi – 49900 , MPa – 344	Psi – 39900 , MPa – 275	20 %

Titanium Ball Valve Equivalent

STANDARD	WERKSTOFF NR.	UNS
Titanium Grade2	3.7035	R50400

Top Titanium Ball Valve Manufacturing Company in Manila

At Curtis Tube Fittings, we are the largest supplier, manufacturer, and exporter of Titanium Ball Valve in Manila, Philippines. Our advanced manufacturing facilities, strategically positioned in the Philippines, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Titanium Ball Valve

Titanium Alloy High Pressure Ball Valve in Baguio, Titanium 2 Way Ball Valve Supplier in Cebu City, Titanium 3 Way Ball Valve in Manila, Philippines, Titanium Alloy 3 Way Ball Valve Price List in Manila, Titanium 5 Way Ball Valve Price in Baguio, Titanium Instrumentation Ball Valve Price in Davao City, Titanium Compression Ball Valve Supplier in Cebu City, Titanium Hydraulic Ball Valve Manufacturer in Manila

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Manufacturer and Supplier of Titanium Ball Valve in Manila, Philippines

Curtis Tube Fittings is a leading supplier and stockist of premium Titanium Ball Valve in Manila, Philippines. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Titanium Ball Valves Uses

Titanium Ball Valves are popular in applications that need corrosion resistance, strength, and low weight. They are critical in the aerospace sector for use in fuel systems as well as hydraulic lines because of their weight-to-strength ratio. In the marine and offshore industries, titanium ball valves resist saltwater corrosion, thus being best suited for piping systems. They also find application in chemical processing to process aggressive fluids and gases. In addition, titanium ball valves can be used in the oil and gas, power generation, and medical sectors for critical flow control and high-pressure applications.
