Curtis Tube Fittings, based in Manila, Philippines, stands out as a top manufacturer and supplier of high-quality fluid control solutions, with a special focus on Duplex Steel Tube Fittings. These fittings are celebrated for their remarkable resistance to corrosion, impressive mechanical strength, and long-lasting durability, making them perfect for creating reliable, leak-free connections in tough industrial, chemical, and offshore piping systems. At Curtis Tube Fittings, they blend precision engineering with cutting-edge manufacturing techniques and rigorous quality control to produce components that are built to last and perform exceptionally well. Their Duplex Steel Tube Fittings find extensive use in the oil and gas, chemical, petrochemical, and power generation sectors, providing safe, efficient, and robust solutions for transporting fluids under high pressure and in corrosive environments.
Made primarily from duplex stainless steel, Duplex Steel Tube Fittings combine both austenitic and ferritic phases, which gives them outstanding corrosion resistance, mechanical strength, and the ability to withstand stress corrosion cracking. These fittings are crafted with precision-machined ends, threads, and joints to guarantee tight, leak-free connections. They excel in durability, even when faced with high pressure, temperature fluctuations, and exposure to harsh or corrosive fluids. These mechanical properties make Duplex Steel Tube Fittings the go-to choice for applications that require dependable, long-term performance, structural integrity, and efficient fluid transport in challenging industrial, chemical, and offshore settings.
| Specification | ASTM A276, ASTM A182 ASME SA479, ASME SA182 |
| Tube Size | 1/16 OD to 2 OD, Od to 50mm OD |
| Type | Seamless/ Welded/Fabricated |
| Thread | BSPT, UNF, SAE, BSP, NPT, ISO, etc. |
| Material Grades | Duplex 2205 Duplex S31803 Duplex S32205 |
| PTFE Standard | ASTM D1710 and D3294 |
| Pressure Rating | 1000/300/6000/3000/10000 PSI for Duplex Steel |
| Temperature | 150-400°C |
| PACKING DETAIL | size of the wooden box – 38*27*17CM size of carton – 21*16*14CM/31*21*16CM/36*45*50CM |
Duplex SS Seamless Compression Fittings :
Size: 1/8 to 2
Pressure Rating: 3000 psi to 10000 psi
Threads: NPT, BSPT, BSPP
Duplex SS Welded Compression Fitting and Tube Adapters :
Size: 24 to 94 and Custom
Pressure Rating: 30000 psi to 10000 psi
Threads: NPT, BSPT, BSPP
| Threads Dimension of BSPP and BSPT | |||||||||
| SIZE | PITCH & SIZE | OD THREAD | OD THREAD | ID THREAD | ID Thread | ||||
| DASH | BSPP & BSPT | MALE BSPT | MALE BSPP | FEMALE BSPT | FEMALE BSPP | ||||
| Inch to TPI | mm | inch | mm | inch | mm | inch | mm | inch | |
| -4 | 1/4 to 19 | 12,8 | 0.5 | 13,0 | 0.51 | 11,2 | 0.44 | 11,9 | 0.47 |
| -2 | 1/8 to 28 | 9,5 | 0.37 | 9,6 | 0.38 | 8,4 | 0.33 | 8,6 | 0.34 |
| -6 | 3/8 to 19 | 16,3 | 0.64 | 16,5 | 0.65 | 14,7 | 0.59 | 15,2 | 0.6 |
| -10 | 5/8 to 14 | 22,5 | 0.89 | 22,8 | 0.9 | 20,6 | 0.81 | 20,8 | 0.82 |
| -8 | 1/2 to 14 | 20,4 | 0.8 | 20,8 | 0.82 | 18,3 | 0.72 | 19,1 | 0.75 |
| -12 | 3/4 to 14 | 25,9 | 1.02 | 26,3 | 1.04 | 23,9 | 0.94 | 24,6 | 0.97 |
| -20 | 1.1/4 to 11 | 41,1 | 1.62 | 41,8 | 1.64 | 38,6 | 1.52 | 39,4 | 1.55 |
| -16 | 1 to 11 | 32,6 | 1.28 | 33,1 | 1.3 | 29,7 | 1.17 | 30,7 | 1.21 |
| -24 | 1.1/2 to 11 | 47,0 | 1.85 | 47,7 | 1.88 | 44,5 | 1.75 | 45,5 | 1.79 |
| -40 | 2.1/2 to 11 | 74,1 | 2.92 | 75,1 | 2.95 | 71,9 | 2.83 | 72,6 | 2.86 |
| -32 | 2(11) | 58,6 | 2.31 | 59,5 | 2.34 | 56,4 | 2.22 | 57,4 | 2.26 |
| -48 | 3 to 11 | 86,6 | 3.41 | 87,9 | 3.46 | 84,6 | 3.33 | 85,4 | 3.36 |
Contact us to get a quick quote for your requirement.
Venton Tube Fittings is the premier supplier, manufacturer and exporter of Duplex Steel Tube Fittings in Manila, Philippines. Our strategic manufacturing units placed in the Philippines allow us to supply high-quality solutions customized to your needs. We value Efficiency and Excellence. Ensuring that our products meet the highest industry standards. Maintaining a well-stocked inventory we are always ready to ship orders in time and reliably. Our dedication to customer satisfaction compels us to deliver strong and reliable solutions for a wide range of industrial uses.
Duplex Steel Tube Fittings are widely utilized in industries that require strong, reliable, and corrosion-resistant piping solutions. In chemical and petrochemical plants, they ensure the safe transport of aggressive fluids under high pressure. They play a crucial role in oil and gas, offshore, and marine applications, providing leak-free pipelines and process systems. In power generation, industrial machinery, and manufacturing facilities, these fittings guarantee durable and efficient fluid connections. Moreover, they are also used in water treatment, hydraulic systems, and various industrial applications, showcasing their versatility and reliability across different sectors.
Please feel free to contact us if you need any further information or for enquiry.
