Curtis Tube Fittings, Manila, Philippines is a well-known manufacturer of high-quality tube fittings for aerospace, chemical processing, marine, and energy industries. The company specializes in precision-engineered products and durable tube fittings that are built to international standards and deliver high performance in hostile environments. Zirconium 702 tube fittings, which are produced from commercially pure zirconium (Grade 702), exhibit superior corrosion resistance, particularly in aggressive chemical conditions. Available in several forms such as elbows, tees, and reducers, these fittings are well suited for use in nuclear power, marine, and chemical applications because of their heat resistance, strength, and high mechanical properties.
Zirconium 702 tube fittings contain 99.2% zirconium, with minor concentrations of hafnium (up to 4.5%), and trace impurities such as iron, nitrogen, and carbon. They have very good mechanical properties, with tensile strength of about 55,000 psi (379 MPa), yield strength of 30,000 psi (207 MPa), and elongation of 16%. Their physical characteristics are a density of 6.51 g/cm³, melting point of 1852°C (3366°F), and excellent corrosion resistance, which makes them suitable for applications in hostile environments such as chemical processing and nuclear industries.
BRAND NAME | Curtis Tube Fittings |
|---|---|
Equivalent To | SWAGELOK, PARKER, DK-LOK, HOKE |
ASTM SPECIFICATION | ASTM B653/ ASME SB653 |
TUBE SIZE | 1/8’’ to 2’’ and 3mm to 50mm |
MATERIAL GRADES | Zirconium 702 |
THREAD | UNF, BSPT, NPT, BSP, SAE, ISO etc. |
PRESSURE RATING | 300/1000/3000/6000/10000PSI for Zirconium 702 Tube Fittings |
ASTM STANDARDS | ASTM D3294 and D1710 |
APPLICABLE TEMPERATURE | 150-400°C |
PACKING DETAILS |
|
| Compositions | Data |
| Zr+Hf | ≥99.2 |
| Hf | ≤4.5 |
| Fe+Cr | ≤0.2 |
| H | ≤0.005 |
| N | ≤0.025 |
| C | ≤0.05 |
| O | ≤0.16 |
| Properties | Metric | Metric |
| Tensile strength (annealed) | 330 MPa | 47900 ps |
| Yield strength (annealed) | 230 MPa | 33400 ps |
| Modulus of elasticity | 94.5 GPa | 13700 ksi |
| Poissons ratio | 0.34 | 0.34 |
| Elongation at break (annealed) | 32% | 32% |
| Hardness, Brinell | 145 | 145 |
| Hardness, Rockwell A | 49 | 49 |
| Hardness, Rockwell B | 78 | 78 |
| Hardness, Vickers (annealed sample) | 150 | 150 |
At Curtis Tube Fittings, we are the largest supplier, manufacturer, and exporter of Zirconium 702 Tube Fittings in Manila, Philippines. Our state-of-the-art manufacturing facilities, strategically located in the Philippines, enable us to deliver high-quality solutions tailored to your specific requirements. With a substantial inventory of over 16,000 tons of premium Zirconium materials, we are well-equipped to fulfill your needs promptly. Our commitment to excellence and efficiency ensures that we consistently maintain available stock to support your demands, making us your trusted partner for Zirconium 702 Tube Fittings.
| grade | UNS | ASTM/ASME | W.Nr. | AFNOR |
|---|---|---|---|---|
| Zr 702 | R60702 | B653 | – |
Curtis Tube Fittings is a leading supplier and stockist of premium Zirconium 702 Tube Fittings in Manila, Philippines. Our products are extensively utilized across various industries, including chemical processing and aerospace, where exceptional corrosion resistance is critical. We are committed to delivering outstanding service and ensuring high customer satisfaction. Our distinctive finishing techniques differentiate us in the metal industry, enhancing the quality and performance of our Zirconium fittings. We are dedicated to consistently providing top-quality products while effectively addressing the specific needs of our customers.
Contact us to get a quick quote for your requirement.
Zirconium 702 tube fittings find extensive application in industries that demand superior corrosion resistance and high performance in harsh environments. They are critical in chemical processing for the handling of aggressive acids and corrosive chemicals. In the nuclear sector, they are utilized because of their low neutron absorption and high thermal resistance. They also find critical application in marine use, withstanding seawater corrosion. Besides, Zirconium 702 tube fittings are used in aerospace, pharmaceuticals, and medical devices where toughness, biocompatibility, and resistance to harsh conditions are of essence.
