Curtis Tube Fittings is a well-known manufacturer and supplier of high-strength aluminum bronze tube fittings in Manila, Philippines. As a company focused on precision engineering and reliability, it provides corrosion-resistant and long-lasting solutions for industrial use. Aluminum bronze tube fittings are highly regarded for their superior strength, wear resistance, and resistance to harsh environments. These fittings are extensively applied in marine, aerospace, chemical processing, and heavy machinery industries, providing better performance in corrosive and high-pressure applications.
Aluminum bronze tube fittings consist mainly of copper (75-95%), aluminum (5-12%), and traces of iron, nickel, and manganese. This composition provides them with better corrosion resistance, especially in marine and acidic environments. Mechanically, they have high tensile strength, good wear resistance, and high impact strength, which makes them suitable for critical applications where high stress is involved. They possess good physical properties with high melting point, good thermal and electrical conductivity, and low coefficient of friction, which ensures reliability and efficiency even in severe industrial environments. The strong construction provides leak-proof connections with negligible risk of leakage.
|
Types |
Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories |
|---|---|
|
Equivalent To |
SWAGELOK, PARKER, DK-LOK, HOKE |
|
Grade |
AB1, AB2 |
|
Sizes |
1/8’’ to 2’’ and 3mm to 50mm |
|
Ends |
Threaded, Welding, JIC |
|
Pressure Rating |
1000 Psi, 3000 Psi, 6000 Psi, 10000 Psi |
|
Threads |
NPT , BSPT, BSPP |
| Element | Content (%) |
|---|---|
| Copper, Cu | 82.7 |
| Aluminium, Al | 12.5-13.5 |
| Iron, Fe | 3.5-5.0 |
| Manganese, Mn | ≤2.0 |
| Other | ≤0.5 |
| Properties | Metric | Imperial |
|---|---|---|
| Hardness, Rockwell C | 27 | 27 |
| Tensile strength (M30 and O61 tempers) | 690 MPa | 100000 psi |
| Yield strength (M30 and O61 tempers) | 380 MPa | 55100 psi |
| Elongation at break (in 50 mm, 1% reduction in area) | 1.00% | 1.00% |
| Elastic modulus | 117 GPa | 17000 ksi |
| Compressive yield strength (at permanent set of 0.1%) | 450 MPa | 65300 psi |
| Compressive yield strength (at permanent set of 1%) | 880 MPa | 128000 psi |
| Poisson’s ratio | 0.34 | 0.34 |
| Charpy impact (@ 18.0 – 100°C/ -0.400 – 212°F, keyhole) | 3.00 J | 2.21 ft-lb |
| Izod impact (@ 18.0 – 100°C/ -0.400 – 212°F) | 3.00 J | 2.21 ft-lb |
| Fatigue strength (@# of cycles 1.00e+8, M30 temper) | 460 MPa | 66700 psi |
| Machinability (UNS C36000 (free-cutting brass) = 100) | 20 | 20 |
| Shear modulus | 42.3 GPa | 6140 ksi |
Venton Tube Fittings is the premier supplier, manufacturer and exporter of Aluminum Bronze Tube Fittings in Manila, Philippines. Our strategic manufacturing units placed in the Philippines allow us to supply high-quality solutions customized to your needs. We value Efficiency and Excellence. Ensuring that our products meet the highest industry standards. Maintaining a well-stocked inventory we are always ready to ship orders in time and reliably. Our dedication to customer satisfaction compels us to deliver strong and reliable solutions for a wide range of industrial uses.
| Properties | Metric | Imperial |
|---|---|---|
| Density | 7.21 g/cc | 0.260 lb/in³ |
| Melting point | 1047°C | 1917°F |
Venton Tube Fittings is a trusted and exporter of top-quality Aluminum Bronze Tube Fittings Philippines. Our products are used widely across diverse industries, proving our commitment to excellence and customer satisfaction. Our unique finishing processes set us apart in the metal istockist ndustry. We assure premier product quality and reliability. Our dedication to innovation and precision, enables us to provide to the evolving needs of our clients while maintaining the highest standards of service.
Contact us to get a quick quote for your requirement.
Aluminum bronze tube fittings are extensively utilized in high-strength and corrosion-resistant industries. In marine systems, they have superior seawater corrosion resistance and are thus employed in ship construction and offshore installations. In heavy machinery and aerospace, they endure high pressures and mechanical stress. They are utilized in chemical plants for the processing of corrosive fluids. They also have uses in oil and gas, desalination, and power generation sectors, where their resistance to wear, heat, and aggressive chemicals guarantees long-term and effective operation.
Please feel free to contact us if you need any further information or for enquiry.
