Curtis Tube Fittings, located in Manila, Philippines, stands out as a leading manufacturer and supplier of top-notch fluid control solutions, with a special focus on Polypropylene (PP) Ball Valves. These valves are celebrated for their impressive chemical resistance, lightweight design, and user-friendly operation, making them a reliable choice for a wide range of industrial applications. At Curtis Tube Fittings, precision engineering meets rigorous quality control, resulting in durable and efficient valves that guarantee accurate flow regulation. Their PP Ball Valves find extensive use in sectors like chemical processing, water treatment, agriculture, and industrial piping systems, providing long-lasting performance, operational safety, and resistance to corrosion and wear.
Constructed from high-grade polypropylene, these PP Ball Valves are a robust thermoplastic known for its outstanding chemical resistance and lightweight characteristics. They come equipped with a precision-molded ball and seat, which ensures smooth operation and a tight seal even under pressure. Thanks to polypropylene’s ability to withstand acids, alkalis, and various corrosive substances, these valves are perfect for managing aggressive fluids. They boast mechanical stability, high impact resistance, and thermal tolerance, making them suitable for diverse industrial settings. The blend of strength, corrosion resistance, and reliability makes PP Ball Valves a smart choice for long-term use in challenging fluid control scenarios.
| Material Of Construction | Unplasticized Poly Vinyl Chloride | Construction | Multi Piece Body |
| Design | Single body moulded | Test pressure | 07 kg./cm2 |
| Max working temp | 60 c (consistently) | Size Range | 15 m to 80 mm |
| Connection End | Solid Plain and Ball Valve | Standard | As per requirement |
| Material Specification | |||
| No. | DESCRIPTION | QTY. | MATERIAL |
| 1) | Flanged end | 2 | PP / HDPE & PVDF |
| 2) | Body | 1 | PP / HDPE & PVDF |
| 3) | Ball | 1 | PP & PVDF |
| 4) | Stem/Spindal | 1 | Polypropylene With M.S. /S.S |
| 5) | Seat Ring | 2 | PTFE (TEFLON) |
| 6) | Body”O”Ring | 2 | Neoprene |
| 7) | Stem Seal Ring | 1 | PTFE (TEFLON) |
| 8) | Stem “O” Ring | 1 | Neoprene |
| 9) | Stud, Nut & Washer | REQ | M.S. Zinc Plated/S.S |
| 10) | Nut Cap | REQ | Polypropylene. |
| 11) | Handle | 1 | M.S. PP Coated. |
| 12) | Handle Hex. Pin | 1 | M.S./ S.S. |
| 13) | Handle Cap | 1 | Polypropylene. |
| Size | L | T | OD | ID | H1 | H | |
| In. | MM | ||||||
| 1/2″ | 15MM | 129 | 12.5 | 100 | 13.5 | 130 | 69 |
| 3/4″ | 20MM | 142 | 14 | 101 | 19 | 131 | 75 |
| 1″ | 25MM | 160 | 20 | 123 | 24 | 165 | 89 |
| 1 1/2″ | 40MM | 182 | 20 | 140 | 38 | 197 | 109 |
| 2″ | 50MM | 208 | 22 | 165 | 50 | 200 | 121 |
| 2 1/2″ | 65MM | 230 | 25 | 185 | 63 | 255 | 144 |
| 3″ | 80MM | 251 | 25 | 201 | 75 | 255 | 150 |
| 4″ | 100MM | 302 | 28 | 228 | 100 | 350 | 182 |
| 6″ | 150MM | 428 | 30 | 300 | 150 | – | 236 |
| 8″ | 200MM | 505 | 32 | 360 | 201 | – | 325 |
| 10″ | 250MM | 570 | 34 | 425 | 242 | – | 310 |
| 12″ | 315MM | 590 | 35 | 487 | 300 | – | 309 |
Venton Tube Fittings is the premier supplier, manufacturer and exporter of PP Ball Valve in Manila, Philippines. Our strategic manufacturing units placed in the Philippines allow us to supply high-quality solutions customized to your needs. We value Efficiency and Excellence. Ensuring that our products meet the highest industry standards. Maintaining a well-stocked inventory we are always ready to ship orders in time and reliably. Our dedication to customer satisfaction compels us to deliver strong and reliable solutions for a wide range of industrial uses.
Venton Tube Fittings is a trusted and exporter of top-quality PP Ball Valve Philippines. Our products are used widely across diverse industries, proving our commitment to excellence and customer satisfaction. Our unique finishing processes set us apart in the metal istockist ndustry. We assure premier product quality and reliability. Our dedication to innovation and precision, enables us to provide to the evolving needs of our clients while maintaining the highest standards of service.
Contact us to get a quick quote for your requirement.
In industries where dependable flow control and chemical resistance are crucial, PP Ball Valves are a go-to solution. In chemical processing facilities, they effectively handle aggressive and corrosive fluids. They’re also commonly used in water treatment systems, irrigation, and agriculture for efficient fluid distribution. In the realm of industrial piping and manufacturing, these valves excel at providing precise shut-off and flow regulation. Their lightweight and sturdy design simplifies installation and maintenance, while their corrosion resistance ensures they stand the test of time. Additionally, these valves find applications in laboratories, wastewater treatment, and chemical storage systems.
Please feel free to contact us if you need any further information or for enquiry.
