We are a top-notch manufacturer and supplier of Curtis tube fittings in Manila, Philippines, providing high-performance 10,000 PSI Ball Valves. They are heavy-duty valves with the capability to handle extreme pressure applications, delivering accurate and reliable flow control. They are made of high-quality material and offer superior corrosion resistance, wear resistance, and high-temperature resistance. Our 10,000 PSI Ball Valves are up to international industry standards, which is why they are well-suited for rigorous applications in oil & gas, hydraulic systems, chemical processing, and industrial fluid control operations.
10,000 PSI Ball Valves are usually manufactured of high-strength stainless steel (SS 316, SS 304), carbon steel, or alloy steel in order to achieve durability and resistance to pressure. Their alloy structure consists of iron, chromium (16-20%), nickel (8-12%), and molybdenum (for SS 316), which strengthen and are more resistant to corrosion. From the mechanical viewpoint, these valves have a tensile strength ranging between 550-750 MPa, yield strength ranging from 250-450 MPa, and an elongation range between 20-30%. Having a density of approximately 7.8-8.0 g/cm³ and high thermal conductivity, they work well under severe operating conditions.
| VALVE SIZE | 1/8″ TO 2″ / 6 MM TO 50 MM |
| THREAD | NPT, BSPP, BSPT, JIC, METRIC, UNF |
| CONNECTION | THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE |
| FUNCTION | 2 WAY, 3 WAY |
| PRESSURE RATING | 10000 PSI (700 BAR) |
| SEAL RING MATERIAL | PTFE, PVDF, DELRIN, PEEK, GRAPHITE |
| STANDARD | ISO , DIN , ANSI , API , ASME , AWWA , MSS , |
| MEDIA | HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL |
| MEDIA TEMPERATURE | (-120* C TO 500*C )RANGE AS PER PRESSURE |
| BODY TYPE | BAR STOCK |
| BRAND NAME | TU-LOK |
| PACKING DETAILS | BOX PACKING, WOODEN PALLET |
| MATERIAL | CS, SS 304, SS 316, SS 316 TI, BRASS, COPPER, DUPLEX, SUPER DUPLEX, INCONEL, MONEL, HASTELLOY, SMO 254, ALLOY 20, TITANIUM, 904L & ALL OTHER ALLOYS |
| EQUIVALENT BRANDS | SWAGELOK, PARKER, DK-LOK, HAMLET, OLIVER VALVES, HOKE |
| APPLICATION | MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES , POWER GENERATING PLANT , STEEL MANUFACTURING PLANT , MINING INDUSTRIES , CHEMICAL PROCESSING MACHINES , PIPING LINE , PAINT INDUSTRIES , TRUCKS AND TRAILERS , AUTOMATION , AGRICULTURE MACHINES , AEROSPACE & DEFENCE EQUIPMENTS, |
Venton Tube Fittings is the premier supplier, manufacturer and exporter of 10000 PSI Ball Valve
in Manila, Philippines. Our strategic manufacturing units placed in the Philippines allow us to supply high-quality solutions customized to your needs. We value Efficiency and Excellence. Ensuring that our products meet the highest industry standards. Maintaining a well-stocked inventory we are always ready to ship orders in time and reliably. Our dedication to customer satisfaction compels us to deliver strong and reliable solutions for a wide range of industrial uses.
Contact us to get a quick quote for your requirement.
Venton Tube Fittings is a trusted and exporter of top-quality10000 PSI Ball Valve
Philippines. Our products are used widely across diverse industries, proving our commitment to excellence and customer satisfaction. Our unique finishing processes set us apart in the metal istockist ndustry. We assure premier product quality and reliability. Our dedication to innovation and precision, enables us to provide to the evolving needs of our clients while maintaining the highest standards of service.
| IN/OUTLET NPT-F | Dimension | ||||
| L | G | H | B | A | |
| 1/4” | 66 | 110 | 45 | 5 | 34 |
| 3/8” | 77 | 110 | 55 | 8 | 38 |
| 1/2” | 92 | 131 | 67 | 10 | 45 |
| 3/4” | 95 | 135 | 75 | 12 | 48 |
| 1” | 102 | 145 | 80 | 18 | 50 |
10,000 PSI Ball Valves are used in high-pressure applications where reliable and accurate flow control is necessary. They find extensive application in oil & gas industries, hydraulic machinery, and chemical processing plants to manage extreme pressure levels. These valves provide leak-proof and safe operation in water treatment, power generation, and industrial fluid handling processes. Their strong build quality makes them ideal for offshore drilling, high-pressure testing, and other rigorous environments where strength, safety, and efficiency are paramount.
Please feel free to contact us if you need any further information or for enquiry.
