Curtis Tube Fittings, located in Manila, Philippines, has earned a solid reputation as a reliable manufacturer and supplier of top-notch fluid control solutions, with a special focus on 5 Way Ball Valves. These valves are celebrated for their versatility, durability, and precise flow regulation, making them ideal for optimizing complex fluid distribution systems. At Curtis Tube Fittings, advanced engineering meets precision manufacturing, all backed by rigorous quality control to ensure that their valves operate leak-free and stand the test of time. Their 5 Way Ball Valves find applications across various industries, including chemical processing, petrochemicals, oil and gas, water treatment, and pharmaceuticals, offering efficient, dependable, and easy-to-maintain solutions for managing multi-directional flow.
Typically made from stainless steel, brass, or high-grade alloys, 5 Way Ball Valves feature a unique multi-port spherical ball design that allows for fluid direction control through five ports. These valves boast impressive mechanical strength, excellent resistance to pressure and temperature, and are highly resistant to corrosion, ensuring they can withstand tough conditions. The precise machining of the ball and seats guarantees smooth operation, tight sealing, and minimal wear over time. Their sturdy construction and thermal stability make them perfect for handling corrosive chemicals, gases, or liquids, delivering reliable and long-lasting performance in intricate industrial fluid systems.
| Design Standard | BS EN ISO 17292 (BS 5351) / BS EN ISO 12516 / BS EN 1983 / ASME B 16.34 / API 6D |
| Inspection & Testing Standard | BS EN ISO 12266 – I (BS 6755 – I) |
| Flange To Flange Distance | Mfg. Standard |
| End Connection | Flanged End to ANSI B 16.5, Class 150 / 300 |
| BS 10 Table D / E / F / H | |
| PN 6 / PN 10 / PN 16 / PN 25 / PN 40 | |
| DIN Standard / JIS Standard / IS Standard | |
| Manufacturing Size Range | 1/2″ (DN15) to 6″(DN 150) |
| Pressure Rating of Valve | 150# / 300# |
| PN 10 / PN 16 / PN 25 / PN 40 | |
| Valve Operation | Manual Hand Lever / Worm-Gear Actuator Operated |
| Pneumatic Rotary Quarter Turn Actuator / Electrical Actuator |
Venton Tube Fittings is the premier supplier, manufacturer and exporter of (5 Way Ball Valve) in Manila, Philippines. Our strategic manufacturing units placed in the Philippines allow us to supply high-quality solutions customized to your needs. We value Efficiency and Excellence. Ensuring that our products meet the highest industry standards. Maintaining a well-stocked inventory we are always ready to ship orders in time and reliably. Our dedication to customer satisfaction compels us to deliver strong and reliable solutions for a wide range of industrial uses.
Item | Part Name | Material | Qty |
1 | Body | A351 Gr. CF8M | 1 |
2 | End Cap | A351 Gr. CF8M | 3 |
3 | Blind End Cap | A351 Gr. CF8M | 1 |
4 | Ball | 316SS | 1 |
5 | Stem | 316SS | 1 |
6 | Seat | RTFE ( 15% C.F.) | 4 |
7 | Body Seal | PTFE | 4 |
8 | Body Bolt | 304SS | 16 |
9 | Body Bolt Washer | 304SS | 16 |
10 | Thrust Washer | PEEK | 1 |
11 | Stem O-Ring | Viton 90 | 1 |
12 | Stem Packing Set | TFM | 1 |
13 | Packing Gland | 304SS | 1 |
| 14 | Belleville Washer | 301SS | 4 |
| 15 | Gland Nut | 304SS | 1 |
| 16 | Gland Nut Lock Washer | 304SS | 1 |
| 17 | Stop Pin | 304SS | 1 |
| 18 | Stop Plate | 304SS | 1 |
| 19 | Handle | 304SS | 1 |
| 20 | Handle Nut | 304SS | 1 |
| 21 | Handle Cover | Vinyl | 1 |
| 22 | Trunnion Bearing | PEEK | 1 |
| 23 | Trunnion Bolt | 304SS | 3 |
| 24 | Trunnion | 316SS | 1 |
| 25 | Trunnion Gasket | PTFE | 1 |
| 26 | Stem Set Pin | 316SS | 1 |
Contact us to get a quick quote for your requirement.
Venton Tube Fittings is a trusted and exporter of top-quality(5 Way Ball Valve) Philippines. Our products are used widely across diverse industries, proving our commitment to excellence and customer satisfaction. Our unique finishing processes set us apart in the metal istockist ndustry. We assure premier product quality and reliability. Our dedication to innovation and precision, enables us to provide to the evolving needs of our clients while maintaining the highest standards of service.
5 Way Ball Valves are commonly used in industries that demand flexible and precise fluid distribution. In chemical and petrochemical plants, they efficiently and safely manage multiple fluid streams. They play a crucial role in oil and gas operations, water treatment, and industrial process piping systems by controlling and redirecting flow paths. Additionally, these valves are essential in pharmaceutical manufacturing, laboratories, and food and beverage processing, where accurate multi-directional flow control is vital. With their versatility, durability, and ease of maintenance, 5 Way Ball Valves have become indispensable in applications that require reliable fluid management.
Please feel free to contact us if you need any further information or for enquiry.
