Curtis Tube Fittings is a trusted manufacturer and supplier located in Manila, Philippines, specializing in top-notch Stainless Steel 316 Ball Valves. These valves are celebrated for their exceptional corrosion resistance, strength, and durability, making them perfect for demanding fluid control tasks. Crafted with precision to endure high pressure and temperature, they guarantee smooth flow regulation and a long lifespan. Curtis Tube Fittings delivers dependable solutions for various industries, including chemical processing, oil and gas, power generation, and water treatment, positioning their Stainless Steel 316 Ball Valves as a reliable choice for critical industrial operations.
Stainless Steel 316 Ball Valves are primarily made of iron, featuring 16–18% chromium, 10–14% nickel, and 2–3% molybdenum, which significantly boosts their corrosion resistance, particularly in chloride-heavy environments. They boast impressive tensile strength of about 515 MPa, along with high yield strength and good elongation. These valves are known for their remarkable resistance to pitting and crevice corrosion, maintaining their structural integrity even at elevated temperatures. Additionally, they offer excellent toughness, wear resistance, and durability. Their smooth surface finish and outstanding mechanical properties make them ideal for a variety of industrial fluid control systems.
| VALVE SIZE | 1/8″ TO 2″ / 6 MM TO 50 MM |
| THREAD | NPT, BSPP, BSPT, JIC, METRIC, UNF |
| CONNECTION | THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE |
| FUNCTION | 2 WAY, 3 WAY, 4 WAY, 5 WAY, |
| PRESSURE RATING | 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI |
| SEAL RING MATERIAL | PTFE, PVDF, DELRIN, PEEK, GRAPHITE |
| STANDARD | ISO , DIN , ANSI , API , ASME , AWWA , MSS , |
| MEDIA | HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL |
| MEDIA TEMPERATURE | (-120* C TO 500*C )RANGE AS PER PRESSURE |
| BODY TYPE | BAR STOCK |
| BRAND NAME | TU-LOK |
| PACKING DETAILS | BOX PACKING, WOODEN PALLET |
| EQUIVALENT BRANDS | SWAGELOK, PARKER, DK-LOK, HAMLET, OLIVER VALVES, HOKE |
| APPLICATION | MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES , POWER GENERATING PLANT , STEEL MANUFACTURING PLANT , MINING INDUSTRIES , CHEMICAL PROCESSING MACHINES , PIPING LINE , PAINT INDUSTRIES , TRUCKS AND TRAILERS , AUTOMATION , AGRICULTURE MACHINES , AEROSPACE & DEFENCE EQUIPMENTS, |
| Grade | Mn | C | S | Mo | N | Si | P | Cr | Ni | |
| 316 | Minimum | – | – | – | 2.00 | – | – | 0 | 16.0 | 10.0 |
| Maximum | 2.0 | 0.08 | 0.03 | 3.00 | 0.10 | 0.75 | 0.045 | 18.0 | 14.0 | |
| 316H | Minimum | 0.04 | 0.04 | – | 2.00 | – | 0 | – | 16.0 | 10.0 |
| Maximum | 0.10 | 0.10 | 0.03 | 3.00 | – | 0.75 | 0.045 | 18.0 | 14.0 |
|
Grade |
Yield Strength |
Tensile Strength |
Elongation (%) |
Reduction of Area (%) |
Hardness Max |
|
Min (Mpa) |
Min (Mpa) |
Min |
Min (50mm) |
HB |
|
|
Stainless Steel 316 Valves |
170 |
485 |
30 |
50 |
217* |
|
Stainless Steel 316 Valves |
205 |
515 |
30 |
50 |
217* |
| Grade | British | Euronorm | UNS No | SS | JIS | ||
| European Standards | British Standards | DIN No | Name | ||||
| 316 | 58H, 58J | 316S31 | 1.4401 | X5CrNiMo17-12-2 | S31600 | 2347 | SUS 316 |
| 316H | – | 316S51 | – | – | S31609 | – | – |
Venton Tube Fittings is the premier supplier, manufacturer and exporter of (Stainless Steel 316 Ball Valve) in Manila, Philippines. Our strategic manufacturing units placed in the Philippines allow us to supply high-quality solutions customized to your needs. We value Efficiency and Excellence. Ensuring that our products meet the highest industry standards. Maintaining a well-stocked inventory we are always ready to ship orders in time and reliably. Our dedication to customer satisfaction compels us to deliver strong and reliable solutions for a wide range of industrial uses.
Contact us to get a quick quote for your requirement.
Venton Tube Fittings is a trusted and exporter of top-quality(Stainless Steel 316 Ball Valve) Philippines. Our products are used widely across diverse industries, proving our commitment to excellence and customer satisfaction. Our unique finishing processes set us apart in the metal istockist ndustry. We assure premier product quality and reliability. Our dedication to innovation and precision, enables us to provide to the evolving needs of our clients while maintaining the highest standards of service.
Stainless Steel 316 Ball Valves find extensive use in industries that demand high performance and corrosion resistance. They’re commonly found in chemical and petrochemical plants, oil and gas refineries, power generation facilities, and water treatment plants. With their superior flow control and sealing capabilities, they excel at managing corrosive fluids, steam, water, and gas. In the pharmaceutical and food processing sectors, they ensure hygienic and contamination-free operations. Their long lifespan, low maintenance needs, and ability to function under high pressure and temperature make them a go-to choice for essential flow control applications.
Please feel free to contact us if you need any further information or for enquiry.
