Manila, Philippines-based Curtis Tube Fittings is a reputable tube fittings manufacturer and supplier with a reputation for delivering top-quality tube fittings, known for their reliability, accuracy, and performance. Understanding the requirements of the industry well, Curtis has an extensive selection of engineered solutions. Among its flagship products is the Inconel Tube Fittings, which is applicable to rigorous applications. These tube fittings offer superior heat, corrosion, and oxidation resistance, making them ideal for providing trustworthy, long-term connections in high-temperature, high-pressure applications.
Inconel Tube Fittings consist mainly of nickel (about 50-70%), supplemented by other elements such as chromium (14-22%), iron, and molybdenum. Such a composition renders the alloy superior resistance to oxidation at high temperatures, corrosion, and heat creep. Inconel tube fittings possess outstanding mechanical properties such as high tensile strength, high fatigue life, and resistance at high temperatures, usually over 1000°F (537°C). Their physical characteristics, including low thermal expansion and high thermal conductivity, provide sound performance in extreme applications.
| Specifications | ASTM B366 / ASME SB366 |
|---|---|
| Size | 1/16 in. to 2 in. & 2mm to 50 mm. |
| Dimensional Range | 1/16 to 2 inches (imperial); 2 to 50 mm (metric) |
| Working Pressures | Upto 2000 to 6000 PSI |
| Thread Type | NPT – ASME B1.20.1, SAE AS71051 | ISO/BSP Parallel – ISO 228 | ISO/BSP Tapered – ISO 7, BS EN 10226-1 | SAE (Unified) – ASME B1.1 |
| End Connections | NPT, ISO/BP, SAE/MS, AN, weld ends, port connectors, sanitary flanges, tube adapters |
| Types | Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories |
| Equivalent To | SWAGELOK, PARKER, DK-LOK, HOKE |
| Max Working Pressure | 8MPa | 1200psi Depending on The Tubing Material |
| Working Temperature | -40°C—250°C | -40°F—482°F Depending on The Tubing Material |
| Configurations | Straights, elbows, tees, crosses, caps, plugs, nuts and ferrules Chromatograph and Column End |
| Tube Fitting uses & application | |
| Material Test Certificates (MTC) for Tube Fitting as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel Tube Fittings | 0.15 max | 1.00 max | 0.50 max | 0.015 max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.47 g/cm3 | 1413 °C (2580 °F) | 655 MPa, 95000 psi | 310 MPa, 45000 psi | 45 % |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST | OR |
| Inconel Tube Fittings | N06600 | 2.4816 | NC15FE11M | NiCr15Fe | NCF 600 | NA 13 | МНЖМц 28-2,5-1,5 | ЭИ868 |
Venton Tube Fittings is a trusted and exporter of top-quality( Inconel Tube Fittings) Philippines. Our products are used widely across diverse industries, proving our commitment to excellence and customer satisfaction. Our unique finishing processes set us apart in the metal istockist ndustry. We assure premier product quality and reliability. Our dedication to innovation and precision, enables us to provide to the evolving needs of our clients while maintaining the highest standards of service.
Contact us to get a quick quote for your requirement.
Inconel Tube Fittings have extensive applications in industries where high conditions prevail. They are unavoidable in aerospace, chemical processing, and power generation industries, where heat and corrosion resistance is inevitable. These fittings commonly occur in applications like gas turbines, reactors, and heat exchangers where they offer safe, leak-free connections. Due to their high strength and resistance, they are the best for high-temperature and high-pressure applications, which guarantee the reliability and lifespan of industrial systems operating under extreme conditions.
Please feel free to contact us if you need any further information or for enquiry.
