Based in Manila, Philippines, we are a reliable manufacturer and supplier of high-quality Curtis tube fittings, offering top-notch solutions for diverse industrial applications. We are experts in supplying precision-engineered fittings to international standards, providing superior durability and performance. Our fittings are engineered to endure harsh environments, catering to industries like oil and gas, petrochemicals, and power generation with efficient and reliable connection solutions for high-temperature and high-pressure applications.
Stainless Steel Hydraulic Fittings are generally manufactured using high-grade stainless steel alloys such as 304 and 316. They consist of about 18-20% chromium to provide corrosion resistance, 8-12% nickel to enhance strength and toughness, and 2-3% molybdenum (in case of 316) to ensure better resistance against pitting and crevice corrosion. Mechanically, they have a tensile strength of 515-620 MPa, yield strength of 205-310 MPa, and high ductility. Physically, they are of a density of approximately 7.9 g/cm³ and are able to function optimally within an extensive range of temperatures from -270°C to 870°C, promoting durability and effectiveness.
| DESIGN STANDARD | DIN 2353/ ISO 8434-1 |
| MATERIAL | SS 304 ,SS 304L , SS 316 ,SS 316L, SS 316TI ( 1.4571) , SS 310, SS 347 |
| WORKING PRESSURE | (LOW) LL SERIES – 100 BAR |
| (MEDIUM)L SERIES – 100 BAR TO 500 BAR | |
| (HEAVY)S SERIES – 200 BAR TO 800 BAR | |
| SIZE RANGE | LL SERIES – 4LL TO 12LL |
| L SERIES – 6L TO 42L | |
| S SERIES – 6S TO 38S | |
| CONNECTIONS | TUBE TO TUBE , TUBE TO MALE THREAD , TUBE TO FEMALE THREAD , TUBE TO BUTT WELD , TUBE TO SOCKET WELD , TUBE TO JIC 37* , TUBE TO 24* CONE, TUBE TO SWIVEL END , TUBE TO ADJUSTBALE STANDPIPE |
| WELD NIPPLE TO MALE THREAD , WELD NIPPLE TO FEMALE THREAD , WELD NIPPLE TO BUTT WELD , WELD NIPPLE TO SOCKET WELD , WELD NIPPLE TO 24* CONE , WELD NIPPLE TO 37* JIC , WELD NIPPLE TO SWIVEL | |
| BODY TYPE | FORGED, BAR STOCK |
| SURFACE | STAINLESS STEEL – EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH |
| TEMPERATURE | (-60*C TO 400*C) |
| APPLICATIONS & INDUSTRIES | CONSTRUCTION EQUIPMENTS , DRILLING PLATFORMS, HYDRO POWER PLANTS , MACHINE TOOLS , RAILWAY TECHNOLOGY , SHIPBUILDING , WIND TUBRINE , MOBILE HYDRAULIC EQUIPMENT , MINNING , STATIONARY HYDRAULIC EQUIPMENT, INDUSTRIAL HYDRAULICS, INJECTION MOULDING MACHINERY , ALUMINUM DIE-CASTING MACHINERY, SINTERING MACHINERY, STEEL MILLS, HYDRAULIC PRESSES, PAPER PROCESSING MOBILE HYDRAULICS, BUILDING MACHINERY, AGRICULTURAL FORESTRY, LIFTING & MATERIAL HANDLING EQUIPMENT |
| MATERIAL DESIGNATOR | STAINLESS STEEL – ASTM A 276 , ASTM 182 |
| Type | Grade | ASTM A240 Chemical Composition | |||||||||
| ASTM(A240M) | Others(JIS) | C | Si | Mn | P | S | Ni | Cr | Mo | Others | |
| Stainless Steels | 304 | SUS304 | ≤0.07 | ≤0.75 | ≤2.00 | ≤0.045 | ≤0.030 | 8.0/10.5 | 17.5/19.5 | ― | N≤0.10 |
| 304H | 0.04/0.10 | ≤0.75 | ≤2.00 | ≤0.045 | ≤0.030 | 8.0/10.5 | 18.0/20.0 | ― | |||
| 304L | SUS304L | ≤0.030 | ≤0.75 | ≤2.00 | ≤0.045 | ≤0.030 | 8.0/12.0 | 17.5/19.5 | ― | N≤0.10 | |
| 304N | SUS304N1 | ≤0.08 | ≤0.75 | ≤2.00 | ≤0.045 | ≤0.030 | 8.0/10.5 | 18.0/20.0 | ― | N:0.10/0.16 | |
| 304LN | SUS304LN | ≤0.030 | ≤0.75 | ≤2.00 | ≤0.045 | ≤0.030 | 8.0/12.0 | 18.0/20.0 | ― | N:0.10/0.16 | |
| 309S | SUS309S | ≤0.08 | ≤0.75 | ≤2.00 | ≤0.045 | ≤0.030 | 12.0/15.0 | 22.0/24.0 | ― | ||
| 310S | SUS310S | ≤0.08 | ≤1.50 | ≤2.00 | ≤0.045 | ≤0.030 | 19.0/22.0 | 24.0/26.0 | ― | ||
| 316 | SUS316 | ≤0.08 | ≤0.75 | ≤2.00 | ≤0.045 | ≤0.030 | 10.0/14.0 | 16.0/18.0 | 2.00/3.00 | N≤0.10 | |
| 316L | SUS316L | ≤0.030 | ≤0.75 | ≤2.00 | ≤0.045 | ≤0.030 | 10.0/14.0 | 16.0/18.0 | 2.00/3.00 | N≤0.10 | |
| 316H | 0.04/0.10 | ≤0.75 | ≤2.00 | ≤0.045 | ≤0.030 | 10.0/14.0 | 16.0/18.0 | 2.00/3.00 | |||
| 316LN | SUS316LN | ≤0.030 | ≤0.75 | ≤2.00 | ≤0.045 | ≤0.030 | 10.0/14.0 | 16.0/18.0 | 2.00/3.00 | N:0.10/0.16 | |
| 317L | SUS317L | ≤0.030 | ≤0.75 | ≤2.00 | ≤0.045 | ≤0.030 | 11.0/15.0 | 18.0/20.0 | 3.0/4.0 | N≤0.10 | |
| 317LN | SUS317LN | ≤0.030 | ≤0.75 | ≤2.00 | ≤0.045 | ≤0.030 | 11.0/15.0 | 18.0/20.0 | 3.0/4.0 | N:0.10/0.22 | |
| 321 | SUS321 | ≤0.08 | ≤0.75 | ≤2.00 | ≤0.045 | ≤0.030 | 9.0/12.0 | 17.0/19.0 | ― | N≤0.10Ti:5ʷʢC+Nʣ/0.70 | |
| 347 | SUS347 | ≤0.08 | ≤0.75 | ≤2.00 | ≤0.045 | ≤0.030 | 9.0/13.0 | 17.0/19.0 | ― | Nb:10ʷC/1.00 | |
| 904L | SUS890L | ≤0.020 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.035 | 23.0/28.0 | 19.0/23.0 | 4.00/5.00 | N≤0.10Cu:1.0/2.0 | |
| S31254 | ≤0.020 | ≤0.80 | ≤1.00 | ≤0.030 | ≤0.010 | 17.5/18.5 | 19.5/20.5 | 6.0/6.5 | N:0.18/0.25Cu:0.50/1.00 | ||
| SUS317J2 | ≤0.06 | ≤1.50 | ≤2.00 | ≤0.045 | ≤0.030 | 12.00/16.00 | 23.00/26.00 | 0.50/1.20 | N:0.25/0.40 | ||
| Type | Mechanical Properties for Stainless Steel Plates | |||||||
| ASTM(A240M) | Others(JIS) | Tensile Properties | Hardness | |||||
| Yield Strength (Mpa) | Tensile Strength (Mpa) | Elongation (%) | HBW | HRBW | ||||
| AusteniticSteels | 304 | SUS304 | ≥205 | ≥515 | ≥40 | ≤201 | ≤92 | |
| 304H | ≥205 | ≥515 | ≥40 | ≤201 | ≤92 | |||
| 304L | SUS304L | ≥170 | ≥485 | ≥40 | ≤201 | ≤92 | ||
| 304N | SUS304N1 | ≥240 | ≥550 | ≥30 | ≤217 | ≤95 | ||
| 304LN | SUS304LN | ≥205 | ≥515 | ≥40 | ≤217 | ≤95 | ||
| 309S | SUS309S | ≥205 | ≥515 | ≥40 | ≤217 | ≤95 | ||
| 310S | SUS310S | ≥205 | ≥515 | ≥40 | ≤217 | ≤95 | ||
| 316 | SUS316 | ≥205 | ≥515 | ≥40 | ≤217 | ≤95 | ||
| 316L | SUS316L | ≥170 | ≥485 | ≥40 | ≤217 | ≤95 | ||
| 316H | ≥205 | ≥515 | ≥40 | ≤217 | ≤95 | |||
| 316LN | SUS316LN | ≥205 | ≥515 | ≥40 | ≤217 | ≤95 | ||
| 317L | SUS317L | ≥205 | ≥515 | ≥40 | ≤217 | ≤95 | ||
| 317LN | SUS317LN | ≥240 | ≥550 | ≥40 | ≤217 | ≤95 | ||
| 321 | SUS321 | ≥205 | ≥515 | ≥40 | ≤217 | ≤95 | ||
| 347 | SUS347 | ≥205 | ≥515 | ≥40 | ≤201 | ≤92 | ||
| N08904/904L | SUS890L | ≥220 | ≥490 | ≥35 | ≤196 | ≤90 | ||
| S31254 | ≥310 | ≥655 | ≥35 | ≤223 | ≤96 | |||
| SUS317J2 | ≥345 | ≥690 | ≥40 | ≤250 | ≤100 | |||
Venton Tube Fittings is the premier supplier, manufacturer and exporter of Stainless Steel Hydraulic Fittings in Manila, Philippines. Our strategic manufacturing units placed in the Philippines allow us to supply high-quality solutions customized to your needs. We value Efficiency and Excellence. Ensuring that our products meet the highest industry standards. Maintaining a well-stocked inventory we are always ready to ship orders in time and reliably. Our dedication to customer satisfaction compels us to deliver strong and reliable solutions for a wide range of industrial uses.
Contact us to get a quick quote for your requirement.
Venton Tube Fittings is a trusted and exporter of top-quality Stainless Steel Hydraulic Fittings Philippines. Our products are used widely across diverse industries, proving our commitment to excellence and customer satisfaction. Our unique finishing processes set us apart in the metal istockist ndustry. We assure premier product quality and reliability. Our dedication to innovation and precision, enables us to provide to the evolving needs of our clients while maintaining the highest standards of service.
Stainless Steel Hydraulic Fittings are employed in high-pressure and corrosion-resistant fluid systems required by industries. They are crucial in oil and gas, marine, aerospace, automotive, and heavy machinery applications for safe, leak-free hydraulic connections. These fittings provide effective fluid transfer and system integrity in severe temperatures and conditions. They also find application in chemical processing and power generation, where their high resistance to corrosion and mechanical stress and their toughness make them particularly suitable for aggressive and critical use.
