Curtis Tube Fittings, located in Manila, Philippines, stands out as a top manufacturer and supplier of high-quality Monel Tube Fittings. Renowned for their precision engineering, durability, and remarkable resistance to corrosion, these fittings are crafted to deliver reliable performance in tough industrial and marine settings. Curtis takes pride in ensuring that every Monel Tube Fitting adheres to international standards, providing leak-proof connections, mechanical strength, and a long lifespan. Catering to sectors like oil and gas, chemical processing, marine, and power generation, Curtis offers robust solutions that prioritize operational safety, efficiency, and consistent performance.
Monel Tube Fittings are crafted from nickel-copper alloys, primarily featuring nickel with copper, which grants them exceptional resistance to seawater, acids, alkalis, and other corrosive substances. They boast impressive tensile strength, toughness, and ductility, ensuring they maintain structural integrity across a wide range of temperatures and pressures. The alloy’s outstanding resistance to pitting, oxidation, and stress corrosion cracking makes Monel Tube Fittings perfect for critical applications that demand both chemical stability and mechanical durability.
| Monel Tube Fittings specification (ASTM / ASME) | ASTM B366/ ASME SB366 |
|---|---|
| Working Pressure | Up to 6,000psi (based on severity of application) |
| Two-Ferrule Tube Fittings | Pressure Ratings : Up to 11 000 psig (760 bar) |
| Medium-Pressure, Gaugeable | Pressure Ratings: Up to 20 000 psig (1378 bar) Temperature Ratings: Up to 1000°F (537°C) |
| High-Pressure Monel Tube Fittings | Pressure Ratings: Up to 60 000 psig (4134 bar) Temperature Ratings: Up to 1000°F (537°C) Materials of construction: 316 Stainless Steel Tube Fittings, Alloy 2507, Monel 400 Tube fittings |
| Monel Tube Fittings Special sizes | 22mm Monel tube fittings 25mm Monel 400 tube fittings 32mm Monel K500 tube fittings 50mm Monel Ferrule tube fittings |
| End Connections | Types: NPT, ISO/BP, SAE/MS, AN, weld ends, port connectors, sanitary flanges, tube adapters |
| Configurations | Straights, elbows, tees, crosses, caps, plugs, nuts and ferrules Chromatograph and Column End |
| Types | Unions, NPT, medium-pressure cone and thread adapters, male SAE/MS, reducers, port connectors, tube adapters, caps, plugs |
| Monel Ferrule Tube Fittings Sizes | 1/16 to 2 in.; 2 to 50 mm 1/4, 3/8, 1/2, 9/16, 3/4 in.; 6, 10, 12 mm |
| Specification | Items Made from Hex – ASTM B574 ; Items made from Round Bar- ASTM B564 |
| Brand Name | Monel Tube fittings |
| Tube Size | 1/16”OD to 2”OD, 2mm OD to 50mm OD |
| Threads | NPT (ANSI B1.20.1), BSP, BSPT (ISO thread configurations), UNF, SAE etc. |
| PTFE Standards | ASTM D1710, ASTM D3294 |
| Applicable Temperature | 150-400°C |
| Monel Tube Fittings Packing Details |
|
| STANDARD | AFNOR | UNS | BS | WERKSTOFF NR. | GOST | JIS | EN |
| Monel K500 | – | N05500 | – | 2.4375 | – | – | – |
| Monel 400 | NU-30M | N04400 | NA 13 | 2.4360 | МНЖМц 28-2,5-1,5 | NW 4400 | NiCu30Fe |
|
OD |
OD Actual |
Thread Designation – Nominal Size |
Thread per inch |
|
|
(fraction inch) |
(inches) |
(inches) |
NPT |
BSP |
|
5/16 |
0.3125 |
1/16 |
27 |
28 |
|
13/32 |
0.405 |
1/8 |
27 |
28 |
|
35/64 |
0.540 |
1/4 |
18 |
19 |
|
43/64 |
0.675 |
3/8 |
18 |
19 |
|
27/32 |
0.840 |
1/2 |
14 |
14 |
|
1-3/64 |
1.050 |
3/4 |
14 |
14 |
|
1-5/16 |
1.315 |
1 |
11-1/2 |
11 |
|
1-21/32 |
1.660 |
1-1/4 |
11-1/2 |
11 |
|
1-29/32 |
1.900 |
1-1/2 |
11-1/2 |
11 |
|
2-3/8 |
2.375 |
2 |
8 |
11 |
|
2-7/8 |
2.875 |
2-1/2 |
8 |
11 |
|
3-1/2 |
3.5 |
3 |
8 |
11 |
|
4 |
4.0 |
3-1/2 |
8 |
11 |
|
4-1/2 |
4.5 |
4 |
8 |
11 |
|
5-5/8 |
5.563 |
5 |
8 |
11 |
|
6-5/8 |
6.718 |
6 |
8 |
11 |
Contact us to get a quick quote for your requirement.
These fittings are commonly found in oil and gas pipelines, chemical plants, marine systems, and industrial process installations, where they play a vital role in connecting and controlling tubing and piping networks. They are well-suited for managing aggressive chemicals, seawater, and high-pressure fluids. Furthermore, they are utilized in instrumentation, metering, and process control systems, where leak-tight performance, corrosion resistance, and long-term reliability are crucial. Their exceptional mechanical and chemical properties ensure safe, efficient, and enduring operation in challenging industrial environments.
Monel Tube Fittings are generally applied to various industries including marine, chemical processing, and oil and gas. They are corrosion-resistant and therefore perfect for application in piping systems that are subject to harsh chemicals, high-pressure situations, and harsh weather conditions. Some of the popular uses include heat exchangers, offshore oil rigs, and chemical reactors, where performance and strength are essential. The fittings provide leak-free, sure connections in important systems, ensuring efficiency and safety in harsh conditions and avoiding expensive system failure
Please feel free to contact us if you need any further information or for enquiry.
