Curtis Tube Fittings is a well-known manufacturer and supplier located in Manila, Philippines, focusing on high-quality **Inconel 600 Needle Valves** that are engineered for precision, durability, and exceptional resistance to corrosion. With a commitment to cutting-edge engineering and strict quality control, Curtis provides valves that guarantee accurate flow regulation and leak-proof performance, even in the toughest environments. These Inconel 600 Needle Valves are designed to endure high temperatures and harsh chemical exposure, making them perfect for critical industrial applications. Curtis Tube Fittings maintains its reputation for excellence by delivering reliable, high-performance solutions that align with global industry standards.
**Inconel 600 Needle Valves** are primarily made up of nickel (at least 72%), chromium (14–17%), and iron (6–10%), along with trace amounts of copper and manganese. This unique composition offers remarkable resistance to oxidation, carburization, and stress corrosion from chloride ions. In terms of mechanical properties, Inconel 600 boasts a **tensile strength of around 655 MPa**, **yield strength of about 310 MPa**, and maintains good elongation and toughness, even at elevated temperatures. Its exceptional metallurgical stability ensures reliable performance in both cryogenic and high-temperature settings.
| VALVE SIZE | 1/8″ TO 2″ / 6 MM TO 50 MM |
| THREAD | NPT, BSPP, BSPT, JIC, METRIC, UNF |
| CONNECTION | THREADED, TUBE END, BUTT WELD, SOCKET WELD, FLANGE END |
| FLOW PATTERN | STRAIGHT, ANGLE, CROSS PATTERNS |
| FUNCTION | 2 WAY, 3 WAY |
| BODY SHAPE | SQUARE, ROUND, HEXAGON |
| PRESSURE RATING | 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15,000 PSI, 20000 PSI |
| ORIFICE SIZE | 2 MM TO 9.5 MM |
| MEDIA | HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL |
| MEDIA TEMPERATURE | (-120* C TO 500*C ) RANGE AS PER PRESSURE |
| BODY TYPE | BAR STOCK, FORGED |
| HANDLE | BAR T-HANDLE,KNOB HANDLE, WHEEL HANDLE |
| PACKING DETAILS | BOX PACKING, WOODEN PALLET |
| MATERIAL | INCONEL 600 |
| Grade | C | Mn | Si | Fe | S | Cr | Cu | Ni | |
| 600 | min. | – | – | – | 6.0 | – | 14.0 | – | 72.0 |
| max. | 0.15 | 1.0 | 0.5 | 10.0 | 0.015 | 17.0 | 0.5 | – | |
| Grade | Elongation (% in 50mm) min | Strength of Yield 0.2% Proof (MPa) minimum | Strength of Tensile (MPa) minimum | Hardness | |
| Rockwell B (HR B) maximum | Brinell (HB) maximum | ||||
| 600 | 40 | Psi – 45,000 , MPa – 310 | Psi – 95,000 , MPa -655 | – | – |
Venton Tube Fittings is the premier supplier, manufacturer and exporter of (Inconel 600 Needle Valves ) in Manila, Philippines. Our strategic manufacturing units placed in the Philippines allow us to supply high-quality solutions customized to your needs. We value Efficiency and Excellence. Ensuring that our products meet the highest industry standards. Maintaining a well-stocked inventory we are always ready to ship orders in time and reliably. Our dedication to customer satisfaction compels us to deliver strong and reliable solutions for a wide range of industrial uses.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel Alloy 600 | 2.4816 | N06600 | NCF 600 | NA 13 | МНЖМц 28-2,5-1,5 | NC15FE11M | NiCr15Fe |
Contact us to get a quick quote for your requirement.
**Inconel 600 Needle Valves** find extensive use in **chemical processing, petrochemical, aerospace, marine, and power generation** sectors. They are perfect for precise fluid flow control in systems that face high temperatures, acids, and corrosive gases. Typical applications include instrumentation panels, high-pressure pipelines, fuel systems, and heat exchangers. Their ability to resist oxidation and corrosion in both acidic and alkaline environments guarantees reliability and a long service life. These valves are the go-to choice for industries that demand accurate control, safety, and durability in challenging operating conditions.
These valves find extensive use across various industries, including aerospace, chemical processing, oil and gas, and power generation. They play a crucial role in applications that require precise flow regulation, such as high-temperature reactors, pressure systems, and steam lines. By ensuring accurate flow control, they help safeguard equipment from potential damage due to extreme pressures or corrosive materials. Thanks to their impressive resistance to oxidation and heat, Inconel 600 Needle Valves are trusted components in critical systems that require long-lasting performance.
Please feel free to contact us if you need any further information or for enquiry.
