Monel Condensate Pots

Home > Monel >Monel Condensate Pots

Curtis Tube Fittings, located in Manila, Philippines, has earned a solid reputation as a reliable manufacturer and supplier of top-notch Monel Condensate Pots. With a focus on precision engineering, durability, and outstanding corrosion resistance, Curtis designs condensate pots that can handle the tough demands of industries dealing with aggressive and high-temperature fluids. Their Monel Condensate Pots are crafted to meet international standards, guaranteeing dependable operation, leak-proof performance, and a long lifespan even in challenging conditions. Curtis Tube Fittings caters to the oil and gas, chemical, marine, and industrial sectors, providing robust solutions that enhance operational safety, efficiency, and consistent performance in critical condensate collection and drainage tasks.

Monel Type A Condensate Pot with Galvanized Plating Manufacturer Manila, Monel® Alloy Type B Condensate Pot with Zinc Plating Dealer Cebu City, Monel Type C Condensate Pots with 4 Ports Dealers Davao City, Monel Type A Condensate Pots with 2 Ports Exporter In Baguio, UNS N04400 Type B Condensate Pots Exporter In Puerto Princesa, Monel Type C Condensate Pot with Zinc Plating Exporter In Manila, Philippines.

Monel Condensate Pots Specifications
Chemical Compositions Of Monel Alloy Condensing Pot
Sizing Of Monel Alloy Condensing Pot
Top Monel Condensate Pots Manufacturing Company in Manila
Types of Monel Condensate Pots
Largest Monel Condensate Pots Supplier in Manila, Philippines
Monel Condensate Pots Uses
Visit Our Other Products

These Monel Condensate Pots are made from high-performance Monel alloys, which mainly consist of nickel and copper, offering remarkable resistance to corrosion, particularly in seawater, acidic, and chloride-rich environments. They boast excellent tensile strength, toughness, and ductility, ensuring reliable performance under high-pressure and high-temperature situations. Thanks to their superior mechanical properties and corrosion resistance, Monel makes these condensate pots incredibly durable, leak-proof, and perfect for long-term use in demanding industrial and marine settings.

Monel Condensate Pots Specifications

Standard : DIN, ASTM, BS and all International Standards.
Number of Ports : 2 ports upto 8 ports, refer to the section below for arrangements.
Working Pressure : 6000 PSIG(41.34 MPa).
Pressure Rating : 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI.
Header Inlet : 1” Female Bsp or Npt threaded to ASME B16.1 or Flanged inlet optional.
Header Outlet/drain : None / or ¼”Male Bsp or Npt threaded to ASME B16.1 or 150# cast fitting.
Pipe size : 2″, 3″, 4″, 5”, 6” and larger size upon request.
Pipe Schedule : 40, 80, 160, XX seamless pipe.
Total Length : Pipe length 8″,10″,12″ and larger length upon request.
Thread Connections : NPT as per ANSI B1.20.1,Socket weld as per ANSI B16.11, Butt weld as per ANSI B16.9.

Chemical Compositions Of Monel Alloy Condensing Pot

Grade	C	Mn	Si	S	Cu	Fe	Ni
Monel Alloy Condensing Pot	0.30 max	2.00 max	0.50 max	0.024 max	28.00 – 34.00	2.50 max	63.00 min

Sizing Of Monel Alloy Condensing Pot

P NPT – F	Capacity (Internal Vol.0)cm 3±5%	Pressure Rating PSIG	T mm	L mm	B mm
1/4”	150	1800	2.05	135	50.08
1/4”	300	1800	2.05	225	50.08
1/4”	400	1800	2.05	290	50.08
1/4”	500	1800	2.05	350	50.08
1/4”	1000	1800	4.06	275	88.09
1/4”	2250	1800	5.02	435	120
1/4”	3785	1800	5.02	680	120
1/2”	1000	1800	4.06	275	88.09
1/2”	2250	1800	5.02	435	102
1/2”	3785	1800	5.02	680	102
3/4”	1000	1800	4.06	275	88.09
3/4”	2250	1800	5.02	435	102
3/4”	3785	1800	5.02	680	102

Top Monel Condensate Pots Manufacturing Company in Manila

Venton Tube Fittings is the premier supplier, manufacturer and exporter of Monel Condensate Pots
in Manila, Philippines. Our strategic manufacturing units placed in the Philippines allow us to supply high-quality solutions customized to your needs. We value Efficiency and Excellence. Ensuring that our products meet the highest industry standards. Maintaining a well-stocked inventory we are always ready to ship orders in time and reliably. Our dedication to customer satisfaction compels us to deliver strong and reliable solutions for a wide range of industrial uses.

Types of Monel Condensate Pots

Monel Condensate Pot Type A Price in Manila, Monel Type B Condensate Pot with Red Oxide Coated Manufacturer Supplier in Cebu City, Monel Condensate Pot Type C Manufacturer in Davao City, Monel® Alloy Type A Condensate Pot with Red Oxide Coated Price in Baguio, K500 Monel Condensate Pots Type B Manufacturer in Puerto Princesa, 400 Monel Type C Condensate Pot Dealer In Manila, Philippines.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Monel Condensate Pots Supplier in Manila, Philippines

Monel Condensate Pots find their place in steam systems, condensate collection units, heat exchangers, and various industrial process installations where corrosive media or high-temperature fluids are present. They are particularly well-suited for oil and gas platforms, chemical plants, marine operations, and power generation facilities. Moreover, they are utilized in instrumentation, metering, and process control systems to safely collect and drain condensate while ensuring system efficiency, minimal maintenance, and long-lasting reliability. Their exceptional corrosion resistance and mechanical strength guarantee safe and dependable operation in harsh industrial environments.

Monel Condensate Pots Uses

Monel condensate pots have extensive applications across industries like oil and gas, chemical processing, power generation, and marine environments. They help ensure pressure stability by collecting and separating condensate in gas and steam pipes. The pots protect instrumentation and control devices from damage by removing unwanted moisture and impurities. They are well suited for corrosion-resistant applications like offshore drilling platforms, refineries, and heat exchangers. Also, Monel condensate pots are utilized in high-temperature and high-pressure systems where reliability and hardness are needed for smooth
