Stainless Steel Condensate Pots

Home > Stainless Steel > Stainless Steel Condensate Pots

Based in Manila, Philippines, we are a reputable manufacturer and supplier of quality Curtis tube fittings, with high-performance offerings for various industrial uses. Our specialty lies in the production of precision-engineered fittings that can meet international specifications for quality, reliability, and safety. We have a vast product line engineered to resist corrosive and high-pressure conditions for use in various industries like oil and gas, petrochemicals, and power generation. With a devotion to excellence, we provide quality and effective connectivity solutions for high-criticality operations.

Stainless Steel Type D Condensate Pot with Red Oxide Coated Manufacturer Manila, Stainless Steel Type E Condensate Pot with Zinc Plating Dealer Cebu City, SS Type F Condensate Pots Supplier Davao City, 316 Stainless Steel Type D Condensate Pot Exporter In Baguio, Stainless Steel Type E Condensate Pot with Galvanized Plating Sockets Manufacturer Puerto Princesa, Stainless Steel Type F Condensate Pots with 6 Ports Supplier Manila, Philippines.

Stainless Steel Condensate Pots Specifications
Top Stainless Steel Condensate Pots Manufacturing Company in Manila
Types of Stainless Steel Condensate Pots
Sizing Of Stainless Steel Condensing Pot
Largest Stainless Steel Condensate Pots Supplier in Manila, Philippines
Stainless Steel Condensate Pots Uses
Visit Our Other Products

Stainless Steel Condensate Pots are generally constructed of high-grade stainless steel alloys such as 304 and 316. They contain about 18-20% chromium for excellent corrosion resistance, 8-12% nickel for added durability, and 2-3% molybdenum (in 316) for improved resistance to pitting and crevice corrosion. Mechanically, they possess a tensile strength of 515-620 MPa, yield strength of 205-310 MPa, and superior impact resistance. Physically, these pots are about 7.9 g/cm³ in density and can function well in temperatures between -270°C and 870°C, making them long-lasting in extreme conditions.

Stainless Steel Condensate Pots Specifications

Standard : DIN, ASTM, BS and all International Standards.
Number of Ports : 2 ports upto 8 ports, refer to the section below for arrangements.
Working Pressure : 6000 PSIG(41.34 MPa).
Pressure Rating : 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI.
Header Inlet : 1” Female Bsp or Npt threaded to ASME B16.1 or Flanged inlet optional.
Header Outlet/drain : None / or ¼”Male Bsp or Npt threaded to ASME B16.1 or 150# cast fitting.
Pipe size : 2″, 3″, 4″, 5”, 6” and larger size upon request.
Pipe Schedule : 40, 80, 160, XX seamless pipe.
Total Length : Pipe length 8″,10″,12″ and larger length upon request.
Thread Connections : NPT as per ANSI B1.20.1,Socket weld as per ANSI B16.11, Butt weld as per ANSI B16.9.

Top Stainless Steel Condensate Pots Manufacturing Company in Manila

Venton Tube Fittings is the premier supplier, manufacturer and exporter of Stainless Steel Condensate Pots in Manila, Philippines. Our strategic manufacturing units placed in the Philippines allow us to supply high-quality solutions customized to your needs. We value Efficiency and Excellence. Ensuring that our products meet the highest industry standards. Maintaining a well-stocked inventory we are always ready to ship orders in time and reliably. Our dedication to customer satisfaction compels us to deliver strong and reliable solutions for a wide range of industrial uses.

Types of Stainless Steel Condensate Pots

Sizing Of Stainless Steel Condensing Pot

P NPT – F	Capacity (Internal Vol.0)cm 3±5%	Pressure Rating PSIG	T mm	L mm	B mm
1/4”	150	1800	2.05	135	50.08
1/4”	300	1800	2.05	225	50.08
1/4”	400	1800	2.05	290	50.08
1/4”	500	1800	2.05	350	50.08
1/4”	1000	1800	4.06	275	88.09
1/4”	2250	1800	5.02	435	120
1/4”	3785	1800	5.02	680	120
1/2”	1000	1800	4.06	275	88.09
1/2”	2250	1800	5.02	435	102
1/2”	3785	1800	5.02	680	102
3/4”	1000	1800	4.06	275	88.09
3/4”	2250	1800	5.02	435	102
3/4”	3785	1800	5.02	680	102

SS Type D Condensate Pots Price in Manila, SS Type E Condensate Pots Manufacturer Supplier in Cebu City, Stainless Steel Type F Condensate Pot with Red Oxide Coated Manufacturer in Davao City, Stainless Steel 316 Socket Weld Half Couplings Price in Baguio, Stainless Steel Type D Condensate Pot with Galvanized Plating Supplier And Manufacturer in Puerto Princesa, Stainless Steel Type E Condensate Pots with 4 Ports Dealer In Davao City, Stainless Steel Type F Condensate Pot with Galvanized Plating In Manila, Philippines.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Stainless Steel Condensate Pots Supplier in Manila, Philippines

Venton Tube Fittings is a trusted and exporter of top-quality Stainless Steel Condensate Pots Philippines. Our products are used widely across diverse industries, proving our commitment to excellence and customer satisfaction. Our unique finishing processes set us apart in the metal istockist ndustry. We assure premier product quality and reliability. Our dedication to innovation and precision, enables us to provide to the evolving needs of our clients while maintaining the highest standards of service.

Stainless Steel Condensate Pots Uses

Stainless Steel Condensate Pots are utilized to condense and separate condensate, oil, and other foreign matter from steam or gas lines for precise pressure measurement and safeguarding sensitive instruments. They find extensive application in the oil and gas, petrochemical, power generation, and chemical processing industries. Stainless Steel Condensate Pots protect pressure gauges and transmitters from damage by providing a steady fluid barrier. Their resistance to corrosion and high-pressure as well as low-temperature endurance make them best suited for the harsh conditions found in industry.
