Operated from Manila, Philippines, our business is a top-tier producer and distributor of superior-quality Curtis tube fittings, catering to numerous industries with carefully engineered products. Dedicated to excellence, we offer robust and reliable fittings that conform to international standards of performance and safety. Our sophisticated manufacturing techniques provide products that can handle high-pressure and tough environments, making us a go-to partner for such industries as oil and gas, petrochemical, and industrial use.
Swivel pipe adaptors are usually constructed of high-strength materials like stainless steel (e.g., 304 or 316), carbon steel, or brass that offer great corrosion resistance and durability. Mechanically, they possess good tensile strength (up to a maximum of 600 MPa for stainless steel), improved fatigue strength, and strength to handle high-pressure uses. Physically, they have a strong structure with a density of about 7.8 g/cm³ (in the case of stainless steel) and exhibit performance across a broad temperature range (-50°C to 500°C), providing dependable, leak-tight connections in harsh environments.
|
Mcneil Instruments PART # |
END SIZE |
C2 HEX BODY (in.) |
W4 (in.) |
Dynamic Pressure (x 1,000 PSI) |
||||
|
1 UN/UNF-2A |
2 NPSM |
|||||||
|
-S |
-SS |
-B |
||||||
| 0507-4-2 |
7/16 – 20 |
1/8 – 27 |
9/16 |
1.21 |
6.0 |
6.0 |
3.3 |
|
| 0507-4-4 |
7/16 – 20 |
1/4 – 18 |
9/16 |
1.32 |
6.0 |
6.0 |
3.3 |
|
| 0507-5-4 |
1/2 – 20 |
1/4 – 18 |
5/8 |
1.32 |
6.0 |
6.0 |
3.3 |
|
| 0507-6-4 |
9/16 – 18 |
1/4 – 18 |
11/16 |
1.35 |
6.0 |
6.0 |
3.3 |
|
| 0507-6-6 |
9/16 – 18 |
3/8 – 18 |
11/16 |
1.37 |
6.0 |
6.0 |
3.3 |
|
| 0507-6-8 |
9/16 – 18 |
1/2 – 14 |
3/4 |
1.57 |
5.0 |
5.0 |
3.3 |
|
| 0507-8-4 |
3/4 – 16 |
1/4 – 18 |
7/8 |
1.43 |
6.0 |
6.0 |
3.3 |
|
| 0507-8-6 |
3/4 – 16 |
3/8 – 18 |
7/8 |
1.45 |
6.0 |
6.0 |
3.3 |
|
| 0507-8-8 |
3/4 – 16 |
1/2 – 14 |
7/8 |
1.56 |
5.0 |
5.0 |
3.3 |
|
| 0507-8-12 |
3/4 – 16 |
3/4 – 14 |
1 |
1.79 |
4.0 |
4.0 |
2.6 |
|
| 0507-10-6 |
7/8 – 14 |
3/8 – 18 |
1 |
1.59 |
5.0 |
5.0 |
3.3 |
|
| 0507-10-8 |
7/8 – 14 |
1/2 – 14 |
1 |
1.73 |
5.0 |
5.0 |
3.3 |
|
| 0507-10-12 |
7/8 – 14 |
3/4 – 14 |
1 1/4 |
1.88 |
4.0 |
4.0 |
2.6 |
|
| 0507-12-8 |
1 1/16 – 12 |
1/2 – 14 |
1 1/4 |
1.88 |
5.0 |
5.0 |
3.3 |
|
| 0507-12-12 |
1 1/16 – 12 |
3/4 – 14 |
1 1/4 |
1.97 |
4.0 |
4.0 |
2.6 |
|
| 0507-12-16 |
1 1/16 – 12 |
1 – 11 1/2 |
1 1/2 |
2.12 |
3.0 |
3.0 |
1.9 |
|
| 0507-14-12 |
1 3/16 – 12 |
3/4 – 14 |
1 3/8 |
1.97 |
4.0 |
4.0 |
2.6 |
|
| 0507-16-12 |
1 5/16 – 12 |
3/4 – 14 |
1 1/2 |
1.90 |
4.0 |
4.0 |
2.6 |
|
| 0507-16-16 |
1 5/16 – 12 |
1 – 11 1/2 |
1 1/2 |
2.12 |
3.0 |
3.0 |
1.9 |
|
| 0507-20-16 |
1 5/8 – 12 |
1 – 11 1/2 |
1 7/8 |
2.20 |
3.0 |
3.0 |
1.9 |
|
| 0507-20-20 |
1 5/8 – 12 |
1 1/4 – 11 1/2 |
1 7/8 |
2.21 |
2.5 |
2.5 |
1.6 |
|
| 0507-24-24 |
1 7/8 – 12 |
1 1/2 – 11 1/2 |
2 1/8 |
2.39 |
2.0 |
2.0 |
1.3 |
|
| 0507-32-32 |
2 1/2 – 12 |
2 – 11 1/2 |
2 3/4 |
2.49 |
1.5 |
1.5 |
1.0 |
|
Venton Tube Fittings is the premier supplier, manufacturer and exporter of Swivel Pipe Adaptor in Manila, Philippines. Our strategic manufacturing units placed in the Philippines allow us to supply high-quality solutions customized to your needs. We value Efficiency and Excellence. Ensuring that our products meet the highest industry standards. Maintaining a well-stocked inventory we are always ready to ship orders in time and reliably. Our dedication to customer satisfaction compels us to deliver strong and reliable solutions for a wide range of industrial uses.
Venton Tube Fittings is a trusted and exporter of top-qualitySwivel Pipe Adaptor Philippines. Our products are used widely across diverse industries, proving our commitment to excellence and customer satisfaction. Our unique finishing processes set us apart in the metal istockist ndustry. We assure premier product quality and reliability. Our dedication to innovation and precision, enables us to provide to the evolving needs of our clients while maintaining the highest standards of service.
Contact us to get a quick quote for your requirement.
Swivel pipe adaptors find applications across different industries to offer leak-proof, flexible connections between tubes and pipes. They are found in hydraulic and pneumatic systems for convenient alignment and stress reduction due to motion or vibration. They find applications in the oil and gas, chemical processing, and manufacturing industries for transferring fluids and for pressure control. Their rotation makes it simpler to install and maintain them, enhancing the efficiency of the system and avoiding damage from misalignment or mechanical stress.
Please feel free to contact us if you need any further information or for enquiry.
