Curtis Tube Fittings is a well-respected manufacturer and supplier located in Manila, Philippines, focusing on precision-engineered Union Cross fittings and other tube connection components. Renowned for their quality, reliability, and durability, Curtis Tube Fittings offers products that adhere to international performance and safety standards. They serve a variety of industries, including oil and gas, petrochemical, water treatment, and general manufacturing. Utilizing advanced manufacturing techniques, corrosion-resistant materials, and rigorous quality control, Curtis Tube Fittings guarantees that each Union Cross fitting provides leak-free performance, straightforward installation, and long-lasting service even in tough industrial settings.
Union Cross fittings are generally crafted from high-quality materials like stainless steel, brass, carbon steel, or copper alloys, chosen for their strength and resistance to corrosion. Stainless steel grades such as 304 and 316 deliver outstanding performance under high pressure and temperature conditions. These fittings boast excellent tensile strength, hardness, and ductility, making them dependable for heavy-duty applications. Their mechanical properties—including fatigue resistance, dimensional stability, and weldability—allow them to endure vibration, pressure, and environmental stress, ensuring secure and durable connections at the junction of multiple fluid or gas lines.
| UNION TEE | |||||||||||
| TUBE OD | THREAD UN / UNF | S | L | D | PART NO. | ||||||
| mm | inch | N | mm | mm | mm | ||||||
| 6 | 1/4 | 7/16-20 | 11 | 22.6 | 4.4 | 4F-T | |||||
| 8 | 5/16 | 1/2-20 | 13 | 24.1 | 6 | 5F-T | |||||
| 10 | 3/8 | 9/16-18 | 14 | 26.9 | 7.5 | 6F-T | |||||
| 12 | 1/2 | 3/4-16 | 19 | 31.8 | 9.9 | 8F-T | |||||
| 14/15/16 | 5/8 | 7/8-14 | 22 | 36.8 | 12.3 | 10F-T | |||||
| 18/20 | 3/4 | 11/16-12 | 27 | 42.2 | 15.5 | 12F-T | |||||
| 25 | 1 | 1 5/16-12 | 33 | 46 | 21.5 | 16F-T | |||||
| 28/30/32 | 1 1/4 | 15/8-12 | 41 | 52.3 | 27.5 | 20F-T | |||||
| 35/38 | 1 1/2 | 1 7/8-12 | 48 | 59.2 | 33 | 24F-T | |||||
Venton Tube Fittings is the premier supplier, manufacturer and exporter of Union Cross in Manila, Philippines. Our strategic manufacturing units placed in the Philippines allow us to supply high-quality solutions customized to your needs. We value Efficiency and Excellence. Ensuring that our products meet the highest industry standards. Maintaining a well-stocked inventory we are always ready to ship orders in time and reliably. Our dedication to customer satisfaction compels us to deliver strong and reliable solutions for a wide range of industrial uses.
Union Cross fittings are designed to connect and distribute flow from four intersecting pipes or tubes, creating a secure and detachable connection in intricate piping systems. They are frequently used in hydraulic, pneumatic, and instrumentation systems where several lines need to converge at a central point. These fittings find extensive application in oil refineries, chemical processing plants, water distribution systems, and HVAC setups. Union Cross fittings facilitate easy maintenance, disassembly, and replacement of components without interrupting the entire system, promoting efficiency and reliability.
Contact us to get a quick quote for your requirement.
The Union Cross is extensively utilized in oil and gas, petrochemical, chemical processing, and hydraulic system industries to link and distribute fluid or gas in four intersecting sections of tubes. It finds application in systems demanding multi-directional flow and provides a leak-free, high-pressure connection in complicated piping systems. The Union Cross is especially effective in applications where flow distribution must be divided or combined without sacrificing ease of assembly and disassembly or structural integrity and efficiency of operation.
Please feel free to contact us if you need any further information or for enquiry.
