Curtis Tube Fittings, located in Manila, Philippines, has earned a solid reputation as a reliable manufacturer and supplier of top-notch T Port Ball Valves. These valves are celebrated for their precision engineering, durability, and leak-proof performance, making them perfect for ensuring dependable flow control and directional flow switching in demanding industrial and process systems. Curtis takes pride in guaranteeing that every T Port Ball Valve adheres to international standards, providing mechanical strength, operational reliability, and long-lasting performance. Catering to the oil and gas, chemical processing, marine, and industrial sectors, Curtis delivers robust valve solutions that promise efficiency, safety, and consistent performance even in tough operating conditions.

T Port Ball Valve Supplier in Manila, 3 way T-port Floating Ball Valve Price List in Cebu City, 3 ASME B16.5 2013 Ball Valve Manufacturer in Davao City, T Port End Flanged Ball Valve in Baguio, ASTM A479 SS316 Ball Valve Exporter in Cebu City, ASTM A216 WCB Manufacturer in Puerto Princesa, ASTM A216 WCB Ball Valve In Manila, Philippines.

T Port Ball Valve Specification
Top T Port Ball Valve Manufacturing Company in Manila
Material Code for T Port Ball Valve
Types of T Port Ball Valve
T Port Ball Valve Supplier in Manila, Philippines
T Port Ball Valve Uses
Visit Our Other Products

Constructed from high-quality stainless steel or alloy materials, T Port Ball Valves boast impressive tensile strength, toughness, and resistance to corrosion. Their T-shaped port design allows for flexible flow configurations, whether diverting or mixing streams, all while ensuring a leak-tight operation. These valves are built to endure high-pressure, high-temperature, and corrosive environments, guaranteeing precise and durable flow control in critical applications.

T Port Ball Valve Specification

TYPE :	3 way T-port Floating Ball Valve
PORT :	Full Bore
SIZE :	15 mm to 100mm NB
Pressure Rating :	ASME #150PN 20 ASME #300PN 50
Temperature Range	35 Deg C to 280 Deg C (Soft Seated)
Body Materials	Stainless Steel / Carbon Steel / Alloys
Design Standard	API 6D rev 23; ISO 17292 rev 2004
End Flanges	ASME B16.5 2013
Face to Face Dimension	Non Standard , As per Manufacturer Std
Fire safe design	API-607 Rev 2010
Testing	API 598 Rev 2009
Sour Service	NACE MOR 0175 Rev 2009
Documents	BS/EN 10204-3.1 REV 2004

T Port Ball Valve Supplier in Manila, 3 way T-port Floating Ball Valve Price List in Cebu City, 3 ASME B16.5 2013 Ball Valve Manufacturer in Davao City, T Port End Flanged Ball Valve in Baguio, ASTM A479 SS316 Ball Valve Exporter in Cebu City, ASTM A216 WCB Manufacturer in Puerto Princesa, ASTM A216 WCB Ball Valve In Manila, Philippines.

Top T Port Ball Valve Manufacturing Company in Manila

Venton Tube Fittings is the premier supplier, manufacturer and exporter of T Port Ball Valve in Manila, Philippines. Our strategic manufacturing units placed in the Philippines allow us to supply high-quality solutions customized to your needs. We value Efficiency and Excellence. Ensuring that our products meet the highest industry standards. Maintaining a well-stocked inventory we are always ready to ship orders in time and reliably. Our dedication to customer satisfaction compels us to deliver strong and reliable solutions for a wide range of industrial uses.

Material Code for T Port Ball Valve

SR.NO.	PART NAME	STAINLESS STEEL	CARBON STEEL	QTY
1	BODY	ASTM A351 CF8M	ASTM A216 WCB	1
2	END CONN.	ASTM A351 CF8M	ASTM A216 WCB	1
3	END CONN. SIDE	ASTM A351 CF8M	ASTM A216 WCB	1
4	END CONN. BACK	ASTM A351 CF8M	ASTM A216 WCB	1
5	BALL	ASTM A276 SS316	ASTM A276 SS316	1
6	STEM	ASTM A479 SS316	ASTM A479 SS316	1
7	SEAT	PTFE	PTFE	2
8	SEAT SEAL	GRAPHITE / INCONEL	GRAPHITE / INCONEL	2
9	GLAND	SS316	MS	1
8	GLAND BEARING	DELRIN	DELRIN	1
10	SPACER	SS316	SS316	1
12	STEM THRUST WASHER	GFT	GFT	1
13	BODY SEAL	GRAPHITE	GRAPHITE	1
14	STEM O-RING	VITON	VITON	1
15	BODY SEAL	GRAPHITE	GRAPHITE	2
16	END CONN. O-RING	VITON	VITON	2
17	CAVITY	PTFE	PTFE	2
18	STUD	ASTM A193 GR.B8M	ASTM A193 GR.B7	4
19	NUT	ASTM A193 GR.8M	ASTM A193 GR.2H	4
20	STUD	ASTM A193 GR.B8M	ASTM A193 GR.B7	4
21	NUT	ASTM A193 GR.8M	ASTM A193 GR.2H	4
22	STUD	ASTM A193 GR.B8M	ASTM A193 GR.B7	4
23	NUT	ASTM A193 GR.8M	ASTM A193 GR.2H	4
24	LEVER	SS410	SS410	1
25	ALLEN BOLT	MS	MS	1
26	STOPER	MS	MS	1

Types of T Port Ball Valve

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

T Port Ball Valve Supplier in Manila, Philippines

T Port Ball Valves find extensive use in chemical and petrochemical plants, oil and gas facilities, marine systems, and industrial process pipelines, where they control, divert, or mix the flow of fluids and gases. They are particularly well-suited for instrumentation lines, process control systems, and piping networks that require flexible flow configurations, leak-tight performance, and mechanical reliability. With their exceptional corrosion resistance, strength, and durability, these valves ensure safe, efficient, and long-lasting operation in harsh industrial settings.

T Port Ball Valve Uses

T Port Ball Valves find extensive applications in oil and gas, chemical processing, water treatment, and hydraulic systems for diverting, mixing, or isolating fluid flow. They permit multi-directional flow control, which allows for the redirection of fluids between three independent channels. They are well suited for switching between multiple fluid sources, bypassing systems, or combining flows. Their leak-tight construction and high-pressure capability make them indispensable for effective operation, system flexibility, and accurate fluid management in intricate piping systems.
