Curtis Tube Fittings, based in Manila, Philippines, stands out as a top manufacturer and supplier of premium fluid control solutions, with a special focus on Brass Hydraulic Fittings. These fittings are designed to ensure reliable, leak-free connections in low to medium-pressure hydraulic systems, making fluid transfer both efficient and safe. With a blend of precision engineering, cutting-edge manufacturing techniques, and rigorous quality standards, Curtis Tube Fittings delivers components that are not only durable but also high-performing. Their Brass Hydraulic Fittings find applications across various sectors, including plumbing, automotive, manufacturing, and industrial machinery, thanks to their long-lasting service, resistance to corrosion, and dependable operation—making them a go-to choice for effective hydraulic system management.
Constructed from high-grade brass, an alloy of copper and zinc, Brass Hydraulic Fittings are celebrated for their outstanding corrosion resistance, strength, and longevity. These fittings come with precisely machined threads, couplings, and connectors that guarantee secure, leak-free connections in hydraulic systems. Brass offers excellent mechanical strength, wear resistance, and moderate thermal stability, making these fittings ideal for low to medium-pressure applications. Their unique combination of corrosion resistance, durability, and precision ensures they operate reliably over time, providing efficient performance in a range of industrial, commercial, and residential hydraulic applications.
| DESIGN STANDARD | DIN 2353/ ISO 8434-1 |
| MATERIAL | BRASS |
| WORKING PRESSURE | (LOW) LL SERIES – 100 BAR |
| (MEDIUM) L SERIES – 100 BAR TO 500 BAR | |
| (HEAVY) S SERIES – 200 BAR TO 800 BAR | |
| SIZE RANGE | LL SERIES – 4LL TO 12LL |
| L SERIES – 6L TO 42L | |
| S SERIES – 6S TO 38S | |
| CONNECTIONS | TUBE TO TUBE , TUBE TO MALE THREAD , TUBE TO FEMALE THREAD , TUBE TO BUTT WELD , TUBE TO SOCKET WELD , TUBE TO JIC 37* , TUBE TO 24* CONE, TUBE TO SWIVEL END , TUBE TO ADJUSTBALE STANDPIPE |
| WELD NIPPLE TO MALE THREAD , WELD NIPPLE TO FEMALE THREAD , WELD NIPPLE TO BUTT WELD , WELD NIPPLE TO SOCKET WELD , WELD NIPPLE TO 24* CONE , WELD NIPPLE TO 37* JIC , WELD NIPPLE TO SWIVEL | |
| BODY TYPE | FORGED, BAR STOCK |
| SURFACE | NATURAL FINISH, NICKEL PLATED |
| TEMPERATURE | BRASS – (-60*C TO 175*C) |
| MATERIAL DESIGNATOR | BRASS – ASTM B16 UNS C36000 , ASTM B282 ALLOY 37700 , JIS H3250 C3604 , C3771 , JIS H3250 C3771. |
UNS No. | AS No. | Common Name | BSI No. | ISO No. | JIS No. | Copper % | Zinc % | Lead % | Other |
C21000 | 210 | 95/5 Gilding metal | – | CuZn5 | C2100 | 94-96 | ~5 | | – |
C22000 | 220 | 90/10 Gilding metal | CZ101 | CuZn10 | C2200 | 89-91 | ~10 | | – |
C23000 | 230 | 85/15 Gilding metal | Cz103 | CuZn20 | C2300 | 84-86 | ~15 | | – |
C24000 | 240 | 80/20 Gilding metal | Cz103 | CuZn20 | C2400 | 78.5-81.5 | ~20 | | – |
C26130 | 259 | 70/30 Arsenical brass | Cz126 | CuZn30As | C4430 | 69-71 | ~30 | | Arsenic 0.02-0.06 |
C26000 | 260 | 70/30 Brass | Cz106 | CuZn30 | C2600 | 68.5-71.5 | ~30 | | – |
C26800 | 268 | Yellow brass (65/35) | Cz107 | CuZn33 | C2680 | 64-68.5 | ~33 | | – |
C27000 | 270 | 65/35 Wire brass | Cz107 | CuZn35 | – | 63-68.5 | ~35 | | – |
C27200 | 272 | 63/37 Common brass | Cz108 | CuZn37 | C2720 | 62-65 | ~37 | | – |
C35600 | 356 | Engraving brass, 2% lead | – | CuZn39Pb2 | C3560 | 59-64.5 | ~39 | 2.0-3.0 | – |
C37000 | 370 | Engraving brass, 1% lead | – | CuZn39Pb1 | C3710 | 59-62 | ~39 | 0.9-1.4 | – |
C38000 | 380 | Section brass | Cz121 | CuZn43Pb3 | – | 55-60 | ~43 | 1.5-3.0 | Aluminum 0.1-0.6 |
C38500 | 385 | Free cutting brass | Cz121 | CuZn39Pb3 | – | 56-60 | ~39 | 2.5-4.5 | – |
Venton Tube Fittings is the premier supplier, manufacturer and exporter of (Brass Hydraulic Fittings) in Manila, Philippines. Our strategic manufacturing units placed in the Philippines allow us to supply high-quality solutions customized to your needs. We value Efficiency and Excellence. Ensuring that our products meet the highest industry standards. Maintaining a well-stocked inventory we are always ready to ship orders in time and reliably. Our dedication to customer satisfaction compels us to deliver strong and reliable solutions for a wide range of industrial uses.
Contact us to get a quick quote for your requirement.
Venton Tube Fittings is a trusted and exporter of top-quality(Brass Hydraulic Fittings) Philippines. Our products are used widely across diverse industries, proving our commitment to excellence and customer satisfaction. Our unique finishing processes set us apart in the metal istockist ndustry. We assure premier product quality and reliability. Our dedication to innovation and precision, enables us to provide to the evolving needs of our clients while maintaining the highest standards of service.
Please feel free to contact us if you need any further information or for enquiry.
