Curtis Tube Fittings, located in Manila, Philippines, stands out as a top manufacturer and supplier of **Hastelloy Hydraulic Fittings**. They provide high-quality solutions tailored for tough industrial applications. These fittings are meticulously crafted to ensure **secure and leak-free connections** in hydraulic systems, delivering dependable performance even in **high-pressure and corrosive environments**. By harnessing the exceptional qualities of Hastelloy, Curtis Tube Fittings offers fittings that boast **durability, strength, and resistance to oxidation and chemical attack**, making them perfect for critical operations. Catering to the chemical, petrochemical, and power industries, Curtis Tube Fittings has earned a reputation for providing **efficient, safe, and long-lasting hydraulic solutions**.
Hastelloy Hydraulic Fittings are crafted from **Hastelloy**, a nickel-molybdenum-chromium alloy celebrated for its **outstanding resistance to corrosion, pitting, and oxidizing chemicals**. This alloy showcases **high tensile and yield strength, remarkable toughness, and stability at elevated temperatures**, ensuring reliable performance even under extreme conditions. Its mechanical properties enable hydraulic fittings to maintain **structural integrity, leak-free operation, and an extended service life**, even in harsh chemical and high-pressure settings, making Hastelloy the go-to material for demanding hydraulic applications.
| DESIGN STANDARD | DIN 2353/ ISO 8434-1 |
| MATERIAL | HASTELLOY C276, HASTELLOY C22, HASTELLOY B2 |
| WORKING PRESSURE | (LOW) LL SERIES – 100 BAR |
| (MEDIUM)L SERIES – 100 BAR TO 500 BAR | |
| (HEAVY)S SERIES – 200 BAR TO 800 BAR | |
| SIZE RANGE | LL SERIES – 4LL TO 12LL |
| L SERIES – 6L TO 42L | |
| S SERIES – 6S TO 38S | |
| CONNECTIONS | TUBE TO TUBE , TUBE TO MALE THREAD , TUBE TO FEMALE THREAD , TUBE TO BUTT WELD , TUBE TO SOCKET WELD , TUBE TO JIC 37* , TUBE TO 24* CONE, TUBE TO SWIVEL END , TUBE TO ADJUSTBALE STANDPIPE |
| WELD NIPPLE TO MALE THREAD , WELD NIPPLE TO FEMALE THREAD , WELD NIPPLE TO BUTT WELD , WELD NIPPLE TO SOCKET WELD , WELD NIPPLE TO 24* CONE , WELD NIPPLE TO 37* JIC , WELD NIPPLE TO SWIVEL | |
| BODY TYPE | FORGED, BAR STOCK |
| SURFACE | EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH |
| Hastelloy C276 | Ni | C | Mo | Mn | Si | Fe | P | S | Co | Cr |
| Balance | 0.010 Max | 15.00 – 17.00 | 1.00 Max | 0.08 Max | 4.00 – 7.00 | 0.04 Max | 0.03 Max | 2.5 Max | 14.50 – 16.50 | |
| Hastelloy C22 | Balance | 0.010 Max | 12.5 – 14.5 | 0.50 Max | 0.08 Max | 2 – 6 | 0.02 Max | 0.02 Max | 2.5 Max | 20 – 22. |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation | |
|---|---|---|---|---|---|
| C22 | 8.69 G/Cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 45 % |
| C276 | 8.89 G/Cm33 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40% |
| B2 | 9.2 G/Cm3 | 1370 °C (2550 °F) | Psi – 1,15,000 , MPa –760 | Psi – 52,000 , MPa – 350 | 40% |
| B3 | 9.2 G/Cm3 | 1370 °C (2550 °F) | Psi – 1,15,000 , MPa –760 | Psi – 52,000 , MPa – 350 | 40% |
| C4 | 8.64 G/Cm3 | 1350-1400 °C | 783 | 365 | 55% |
| Hybrid BC1 | 8.83 G/Cm³ | 1343 – 1443°C | 725 | 310 | 40% |
| X | 8.22 G/Cm³ | 1355°C | 655 MPa | 240 MPa | 35% |
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| Hastelloy C22 | N06022 | 2.4602 | – | NiCr21Mo14W | NW 6022 | – | – |
| Hastelloy C276 | N10276 | 2.4819 | – | NiMo16Cr15W | NW 0276 | – | ХН65МВУ |
Venton Tube Fittings is the premier supplier, manufacturer and exporter of (Hastelloy Hydraulic Fittings) in Manila, Philippines. Our strategic manufacturing units placed in the Philippines allow us to supply high-quality solutions customized to your needs. We value Efficiency and Excellence. Ensuring that our products meet the highest industry standards. Maintaining a well-stocked inventory we are always ready to ship orders in time and reliably. Our dedication to customer satisfaction compels us to deliver strong and reliable solutions for a wide range of industrial uses.
Contact us to get a quick quote for your requirement.
These fittings find extensive use in **chemical processing, petrochemical, oil & gas, power generation, and marine industries**, where hydraulic systems are subjected to **high pressure and corrosive conditions**. They are perfect for **piping, fluid transfer, and instrumentation systems**, offering safe, precise, and reliable connections. Their resistance to corrosion, scaling, and chemical attack guarantees **long-term reliability and minimal maintenance**, making them indispensable in critical hydraulic applications. Engineers often choose Hastelloy fittings for systems that demand **robust performance, durability, and efficiency under extreme conditions**.
Please feel free to contact us if you need any further information or for enquiry.
