Curtis Tube Fittings, based in Manila, Philippines, is a leading manufacturer and provider of high-performance tube fittings and associated products. Priced for their accuracy, strength, and capability, Curtis provides solutions to a wide range of industrial markets with dependable solutions. Among their top products, Inconel Hydraulic Fittings are designed to operate under exceptionally demanding conditions. These fittings have better resistance to corrosion, temperature, and pressure and hence are suitable for hydraulic systems under stringent applications in the aerospace, automotive, and chemical processing industries.
Inconel Hydraulic Fittings are produced from high-performance Inconel alloys like Inconel 600 or Inconel 718, comprising nickel (50-70%), chromium (14-23%), and iron as the major elements with trace elements of molybdenum, niobium, and titanium. These alloys provide superior resistance to oxidation, corrosion, and heat in aggressive environments. The fittings exhibit high tensile strength, fatigue life, and superior creep resistance even under extreme pressure and temperature conditions. Their physical properties such as low thermal expansion and high thermal conductivity guarantee superior performance and reliability in high-pressure hydraulic applications.
| DESIGN STANDARD | DIN 2353/ ISO 8434-1 |
| MATERIAL | INCONEL 625, INCONEL 718, INCONEL 825, INCOLOY 800 |
| WORKING PRESSURE | (LOW) LL SERIES – 100 BAR |
| (MEDIUM)L SERIES – 100 BAR TO 500 BAR | |
| (HEAVY)S SERIES – 200 BAR TO 800 BAR | |
| SIZE RANGE | 6 MM TO 42 MM |
| CONNECTIONS | TUBE TO MALE THREAD , TUBE TO BUTT WELD , TUBE TO FEMALE THREAD , TUBE TO SOCKET WELD , TUBE TO TUBE , TUBE TO 24* CONE, TUBE TO JIC 37* , TUBE TO ADJUSTBALE STANDPIPE , TUBE TO SWIVEL END |
| WELD NIPPLE TO FEMALE THREAD , WELD NIPPLE TO MALE THREAD , WELD NIPPLE TO SOCKET WELD , WELD NIPPLE TO BUTT WELD , WELD NIPPLE TO 37* JIC , WELD NIPPLE TO 24* CONE ,WELD NIPPLE TO SWIVEL | |
| BODY TYPE | FORGED, BAR STOCK |
| SURFACE | EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH |
| Inconel | Element (% By Mass) | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Ni | Cr | Fe | Mo | Nb | Co | Mn | Cu | Al | Ti | Si | C | S | P | B | |
| 600 | 72.0 | 14.0–17.0 | 6.0–10.0 | 1.0 | 0.5 | 0.5 | 0.15 | 0.015 | |||||||
| 617 | 44.2–56.0 | 20.0–24.0 | 3.0 | 8.0–10.0 | 10.0–15.0 | 0.5 | 0.5 | 0.8–1.5 | 0.6 | 0.5 | 0.15 | 0.015 | 0.015 | 0.006 | |
| 625 | 58.0 | 20.0–23.0 | 5.0 | 8.0–10.0 | 3.15–4.15 | 1.0 | 0.5 | 0.4 | 0.4 | 0.5 | 0.1 | 0.015 | 0.015 | ||
| 690 | 59.5 | 30 | 9.2 | 0.35 | 0.01 | 0.02 | 0.35 | 0.019 | 0.003 | ||||||
| 718 | 50.0–55.0 | 17.0–21.0 | Balance | 2.8–3.3 | 4.75–5.5 | 1.0 | 0.35 | 0.2–0.8 | 0.65–1.15 | 0.3 | 0.35 | 0.08 | 0.015 | 0.015 | 0.006 |
| X-750 | 70.0 | 14.0–17.0 | 5.0–9.0 | 0.7–1.2 | 1.0 | 1.0 | 0.5 | 0.4–1.0 | 2.25–2.75 | 0.5 | 0.08 | 0.01 | |||
| Yield Strength 0.2% Proof (MPa) min | Tensile Strength (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Brinell (HB) max | Rockwell B (HR B) max | |||
| Psi – 75,000 , MPa – 517 | Psi – 1,35,000 , MPa -930 | 42.5 | – | – |
| Grade | UNS No | Old British | Euronorm | GOST | Japanese JIS | ||
| BS | En | No | AFNOR | ||||
| Inconel 600 Pipe | N06600 | NA 13 | NiCr15Fe | 2.4816 | NC15FE11M | МНЖМц 28-2,5-1,5 | NCF 600 |
| Inconel 625 | N06625 | NA 21 | NiCr22Mo9Nb | 2.4856 | NC22DNB4M | ХН75МБТЮ | NCF 625 |
| Inconel 601 | N06601 | NA 49 | NiCr23Fe | 2.4851 | NC23FeA | XH60BT | NCF 601 |
| Incoloy 825 | N08825 | NA 16 | NiCr21Mo | 2.4858 | NFE30C20DUM | ЭП703 | NCF 825 |
Venton Tube Fittings is the premier supplier, manufacturer and exporter of (Inconel Hydraulic Fittings) in Manila, Philippines. Our strategic manufacturing units placed in the Philippines allow us to supply high-quality solutions customized to your needs. We value Efficiency and Excellence. Ensuring that our products meet the highest industry standards. Maintaining a well-stocked inventory we are always ready to ship orders in time and reliably. Our dedication to customer satisfaction compels us to deliver strong and reliable solutions for a wide range of industrial uses.
Contact us to get a quick quote for your requirement.
Venton Tube Fittings is a trusted and exporter of top-quality(Inconel Hydraulic Fittings) Philippines. Our products are used widely across diverse industries, proving our commitment to excellence and customer satisfaction. Our unique finishing processes set us apart in the metal istockist ndustry. We assure premier product quality and reliability. Our dedication to innovation and precision, enables us to provide to the evolving needs of our clients while maintaining the highest standards of service.
Inconel Hydraulic Fittings find extensive applications in high-strength and corrosion-resistant applications in harsh environments. They are typically used in aerospace, chemical processing, and power generation equipment, where high-pressure and high-temperature conditions are more typical. These fittings are well-suited to hydraulic connections in jet engines, turbines, and reactors. Their resistance to stress corrosion cracking and durability make them a necessity for ensuring the integrity of hydraulic circuits, long-term reliable performance in demanding applications.
Please feel free to contact us if you need any further information or for enquiry.
