Inconel Check Valves are expertly crafted valves made from **Inconel**, a nickel-chromium alloy celebrated for its **remarkable resistance to high temperatures, corrosion, and oxidation**. These valves are specifically designed to **facilitate fluid flow in one direction while effectively preventing backflow**, which is crucial for safeguarding pumps, compressors, and pipelines in vital systems. Thanks to the use of Inconel, these valves maintain **mechanical strength and reliability even in extreme conditions**, including high-pressure and chemically aggressive environments. Perfect for **chemical processing, power generation, oil & gas, and marine applications**, Inconel Check Valves offer **long-lasting, low-maintenance, and trustworthy performance**.
Curtis Tube Fittings, located in Manila, Philippines, is a reputable manufacturer and supplier of Inconel Check Valves, delivering high-quality solutions for demanding industrial settings. These valves are engineered to ensure **consistent one-way fluid flow**, preventing backflow in pipelines, pumps, and critical systems. Curtis Tube Fittings merges precision engineering with the exceptional properties of Inconel, providing valves that endure **extreme temperatures, high pressures, and corrosive conditions**. Catering to the chemical, petrochemical, power generation, and oil & gas industries, Curtis Tube Fittings offers durable, efficient, and low-maintenance check valves that ensure **safe and reliable operation in tough industrial environments**.
| CONNECTION | SOCKET WELD END, TUBE END, THREADED, FLANGE END |
| INSTRUMENTATION VALVES SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| THREADS | BSPP, NPT, METRIC, BSPT,UNF, JIC |
| INSTRUMENTATION VALVES BODY SHAPE | HEXAGON |
| PATTERN FLOW | STRAIGHT |
| INSTRUMENTATION VALVES ORIFICE SIZE | 2 MM – 40 MM |
| EQUIVALENT BRANDS | PARKER, SWAGELOK, DK-LOK, STAUFF, OLIVER VALVES, HAMLET, HOKE |
| RATING PRESSURE | 20000 PSI, 1500 PSI, 10000 PSI, 3000 PSI, 6000 PSI, 15,000 PSI |
| CRACKING PRESSURE | 0.5 BAR |
| TYPE | SPRING TYPE, POPPET TYPE |
| INSTRUMENTATION VALVES MATERIAL | INCONEL |
| MEDIA | SEA WATER , HYDRAULIC AIR, OIL, GAS, WATER, HOT WATER , STEAM, COLD WATER , CHEMICAL |
| BODY TYPE | FORGED, BAR STOCK |
| MEDIA TEMPERATURE | (-50* C – 350*C ) AS PER PRESSURE RANGE |
| INSTRUMENTATION VALVES PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Inconel | Element (% By Mass) | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Mo | Ni | Cr | Fe | Mn | Nb | Co | Cu | Al | Ti | Si | C | B | S | P | |
| 690 | 59.05 | 30 | 9.02 | 0.035 | 0.001 | 0.002 | 0.035 | 0.0019 | 0.0003 | ||||||
| 617 | 8.00 to 10.00 | 44.02 to 56.00 | 20.00 to 24.00 | 3.00 | 0.05 | 10.00 to 15.00 | 0.05 | 0.08 to 1.05 | 0.06 | 0.05 | 0.015 | 0.0006 | 0.0015 | 0.0015 | |
| 600 | 72.00 | 14.00 to 17.00 | 6.00 to 10.00 | 1.00 | 0.05 | 0.05 | 0.015 | 0.0015 | |||||||
| 625 | 8.00 to 10.00 | 58.00 | 20.00 to 23.00 | 5.00 | 0.05 | 3.015 to 4.015 | 1.00 | 0.04 | 0.04 | 0.05 | 0.01 | 0.0015 | 0.0015 | ||
| X-750 | 70.00 | 14.00 to 17.00 | 5.00 to 9.00 | 1.00 | 0.07 to 1.02 | 1.00 | 0.05 | 0.04 to 1.00 | 2.025 to 2.075 | 0.05 | 0.008 | 0.001 | |||
| 718 | 2.08 to 3.03 | 50.00 to 55.00 | 17.00 to 21.00 | Balance | 0.035 | 4.075 to 5.05 | 1.00 | 0.02 to 0.08 | 0.065 to 1.015 | 0.03 | 0.035 | 0.008 | 0.0006 | 0.0015 | 0.0015 |
| Tensile Strength (MPa) min | Elongation (% in 50mm) min | Yield Strength 0.2% Proof (MPa) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | |||
| Psi – 1,35,000 , MPa -930 | 42.5 | Psi – 75,000 , MPa – 517 | – | – |
Venton Tube Fittings is the premier supplier, manufacturer and exporter of (Inconel Check Valves) in Manila, Philippines. Our strategic manufacturing units placed in the Philippines allow us to supply high-quality solutions customized to your needs. We value Efficiency and Excellence. Ensuring that our products meet the highest industry standards. Maintaining a well-stocked inventory we are always ready to ship orders in time and reliably. Our dedication to customer satisfaction compels us to deliver strong and reliable solutions for a wide range of industrial uses.
| Standard | Inconel 600 | Inconel 601 | Inconel 625 | Inconel 718 |
|---|---|---|---|---|
| UNS | N06600 | N06601 | N06625 | N07718 |
| EN | NiCr15Fe | NiCr23Fe | NiCr22Mo9Nb | – |
| BS | NA 13 | NA 49 | NA 21 | – |
| GOST | МНЖМц 28-2,5-1,5 | XH60BT | ХН75МБТЮ | – |
| WERKSTOFF NR. | 2.4816 | 2.4851 | 2.4856 | 2.4668 |
| OR | ЭИ868 | ЭИ868 | ЭИ602 | – |
| JIS | NCF 600 | NCF 601 | NCF 625 | – |
| AFNOR | NC15FE11M | NC23FeA | NC22DNB4M | – |
Inconel Check Valves are crafted from **Inconel**, a nickel-chromium alloy known for its **superior corrosion and oxidation resistance**, even in highly aggressive chemical settings. This alloy delivers **high tensile and yield strength, along with excellent creep and fatigue resistance**.
Contact us to get a quick quote for your requirement.
Inconel Check Valves are used extensively in industries like aerospace, petrochemical, and power generation, where high-pressure and high-temperature conditions are the norm. They are critical where one-way flow control is necessary, stopping backflow in pipelines and the free running of vital machinery. Their corrosion resistance renders them suitable for use with aggressive fluids, like in gas turbines, steam lines, and chemical reactors, to ensure sustained functionality and reduced risk of failure under hostile environments.
Please feel free to contact us if you need any further information or for enquiry.
