Curtis Tube Fittings, located in Manila, Philippines, has built a solid reputation as a reliable manufacturer and supplier of top-notch Inconel Manifold Valves. These valves are celebrated for their precision engineering, impressive durability, and remarkable resistance to high-temperature corrosion, making them perfect for ensuring reliable flow control in tough industrial settings. Curtis takes pride in guaranteeing that every Inconel Manifold Valve adheres to international standards, offering leak-proof operation, robust mechanical strength, and long-lasting reliability. Catering to the oil and gas, chemical, marine, and power generation industries, Curtis provides sturdy solutions that prioritize operational safety, accuracy, and consistent performance even in extreme conditions.
Inconel Manifold Valves are crafted from nickel-chromium-based superalloys, which deliver exceptional resistance to oxidation, scaling, and corrosion in high-temperature and aggressive chemical environments. These valves boast excellent tensile strength, toughness, and ductility, ensuring they maintain their structural integrity under intense pressures and thermal cycling. The outstanding corrosion resistance of Inconel guarantees long-term durability and leak-proof performance, making these valves a go-to choice for critical process and instrumentation applications where reliability is key.
| BRAND NAME | TU-LOK |
| VALVE SIZE | 1/8″ TO 1″ |
| THREAD | NPT, BSPP, BSPT |
| CONNECTION | THREADED, FLANGE END |
| TYPE | R TYPE, T TYPE, H TYPE |
| FUNCTION | 2 WAY, 3 WAY, 5 WAY |
| BODY SHAPE | SQUARE, RECTANGLE |
| PRESSURE RATING | 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15,000 PSI |
| ORIFICE SIZE | 2 MM TO 9.5 MM |
| MEDIA TEMPERATURE | (-120* C TO 500*C ) RANGE AS PER PRESSURE |
| BODY TYPE | BAR STOCK, FORGED |
| HANDLE | BAR T-HANDLE |
| PACKING DETAILS | BOX PACKING, WOODEN PALLET |
| EQUIVALENT BRANDS | SWAGELOK, PARKER, ROSE MOUNT, HAMLET, OLIVER VALVES, HOKE |
| MATERIAL | INCONEL |
| Inconel | Element (% By Mass) | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Mn | Cr | Ni | Nb | Mo | Fe | Al | Co | Si | Cu | S | Ti | C | B | P | |
| 600 | 1.0 | 14.0–17.0 | 72.0 | 6.0–10.0 | 0.5 | 0.5 | 0.015 | 0.15 | |||||||
| 617 | 0.5 | 20.0–24.0 | 44.2–56.0 | 8.0–10.0 | 3.0 | 0.8–1.5 | 10.0–15.0 | 0.5 | 0.5 | 0.015 | 0.6 | 0.15 | 0.006 | 0.015 | |
| 625 | 0.5 | 20.0–23.0 | 58.0 | 3.15–4.15 | 8.0–10.0 | 5.0 | 0.4 | 1.0 | 0.5 | 0.015 | 0.4 | 0.1 | 0.015 | ||
| 690 | 0.35 | 30 | 59.5 | 9.2 | 0.02 | 0.35 | 0.01 | 0.003 | 0.019 | ||||||
| 718 | 0.35 | 17.0–21.0 | 50.0–55.0 | 4.75–5.5 | 2.8–3.3 | Balance | 0.65–1.15 | 1.0 | 0.35 | 0.2–0.8 | 0.015 | 0.3 | 0.08 | 0.006 | 0.015 |
| X-750 | 1.0 | 14.0–17.0 | 70.0 | 0.7–1.2 | 5.0–9.0 | 0.4–1.0 | 1.0 | 0.5 | 0.5 | 0.01 | 2.25–2.75 | 0.08 | |||
| Yield Strength 0.2% Proof (MPa) min | Tensile Strength (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Brinell (HB) max | Rockwell B (HR B) max | |||
| Psi – 75,000 , MPa – 517 | Psi – 1,35,000 , MPa -930 | 42.5 | – | – |
Venton Tube Fittings is the premier supplier, manufacturer and exporter of (Inconel Manifold Valves) in Manila, Philippines. Our strategic manufacturing units placed in the Philippines allow us to supply high-quality solutions customized to your needs. We value Efficiency and Excellence. Ensuring that our products meet the highest industry standards. Maintaining a well-stocked inventory we are always ready to ship orders in time and reliably. Our dedication to customer satisfaction compels us to deliver strong and reliable solutions for a wide range of industrial uses.
| STANDARD | UNS | WERKSTOFF NR. | BS | OR | JIS | AFNOR | GOST | EN |
| Incoloy 800H Pipe | N08810 | 1.4958 / 1.4876 | NA 15(H) | XH32T | NCF 800H | Z8NC33-21 | ЭИ670 | X5NiCrAlTi31-20 |
| Incoloy 800 Pipe | N08800 | 1.4876 | NA 15 | XH32T | NCF 800 | Z8NC32-21 | ЭИ670 | X10NiCrAlTi32-20 |
| Incoloy 800HT Pipe | N08811 | 1.4859 / 1.4876 | NA 15(HT) | XH32 | NCF 800HT | – | ЭИ670 | X8NiCrAlTi32-21 |
| UNS No | Grade | Old British | Euronorm | Japanese JIS | GOST | ||
| En | BS | AFNOR | No | ||||
| N06601 | Inconel 601 | NiCr23Fe | NA 49 | NC23FeA | 2.4851 | NCF 601 | XH60BT |
| N06625 | Inconel 625 | NiCr22Mo9Nb | NA 21 | NC22DNB4M | 2.4856 | NCF 625 | ХН75МБТЮ |
| N06600 | Inconel 600 Pipe | NiCr15Fe | NA 13 | NC15FE11M | 2.4816 | NCF 600 | МНЖМц 28-2,5-1,5 |
| N08825 | Incoloy 825 | NiCr21Mo | NA 16 | NFE30C20DUM | 2.4858 | NCF 825 | ЭП703 |
You’ll find Inconel Manifold Valves widely utilized in oil and gas platforms, chemical and petrochemical plants, marine systems, and power generation facilities, where they play a crucial role in controlling, isolating, and regulating multiple process streams. They’re designed to handle high-temperature fluids, acidic or corrosive media, and high-pressure systems with ease. Moreover, they are essential in instrumentation, metering, and critical process control lines, where leak-tight performance, minimal maintenance, and long-term reliability are a must. Their remarkable mechanical strength and corrosion resistance ensure safe, efficient, and durable operation in even the harshest industrial environments.
Contact us to get a quick quote for your requirement.
These valves find extensive use in sectors like oil and gas, aerospace, chemical processing, and power generation. They are perfect for managing the flow of liquids, gases, and steam in systems that demand precise pressure and flow control. You’ll often see them in high-pressure systems, turbines, reactors, and heat exchangers. Thanks to their resistance to high temperatures, corrosion, and stress corrosion cracking, Inconel Manifold Valves ensure reliable and efficient operation even in the most challenging environments.
Please feel free to contact us if you need any further information or for enquiry.
