We are prominent Curtis tube fittings manufacturers and suppliers in Manila, Philippines, and are dedicated to the production of high-class Stainless Steel 321 Needle Valves. These valves find use in precise control of flow in high-temperature and corrosive services. SS 321 is a titanium-stabilized stainless steel that provides high intergranular corrosion and oxidation resistance, thus being well-suited for severe applications. Made to global standards, our needle valves provide leak-tight performance and reliability in fluid and gas systems employed in industries like aerospace, chemical processing, and power generation.
321 Stainless Steel Needle Valves consist of iron, chromium (17-19%), nickel (9-12%), and titanium (a minimum of five times the carbon content) to stabilize for carbide precipitation. The composition improves high-temperature operation and corrosion resistance. Its mechanical properties include tensile strength of around 515 MPa, yield strength of 205 MPa, and elongation of 40%. Physical it is 7.9 g/cm³, has a melting point of 1398-1446°C, and a very good thermal conductivity, appropriate for harsh environments.
| VALVE SIZE | 1/8″ TO 2″ / 6 MM TO 50 MM |
| THREAD | NPT, BSPP, BSPT, JIC, METRIC, UNF |
| CONNECTION | THREADED, TUBE END, BUTT WELD, SOCKET WELD, FLANGE END |
| FLOW PATTERN | STRAIGHT, ANGLE, CROSS PATTERNS |
| FUNCTION | 2 WAY, 3 WAY |
| BODY SHAPE | SQUARE, ROUND, HEXAGON |
| PRESSURE RATING | 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15,000 PSI, 20000 PSI |
| ORIFICE SIZE | 2 MM TO 9.5 MM |
| MEDIA | HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER, COLD WATER, SEA WATER, CHEMICAL |
| MEDIA TEMPERATURE | (-120* C TO 500*C ) RANGE AS PER PRESSURE |
| BODY TYPE | BAR STOCK |
| HANDLE | BAR T-HANDLE, KNOB HANDLE, WHEEL HANDLE |
| MATERIAL | SS 321 |
| APPLICATION | SUGAR, OIL & GAS, TEXTILE, POWER, WATER & WASTE WATER TREATEMENT, CHEMICAL PROCESS INDUSTRIES |
Venton Tube Fittings is a trusted and exporter of top-quality Stainless Steel 321 Needle Valve Philippines. Our products are used widely across diverse industries, proving our commitment to excellence and customer satisfaction. Our unique finishing processes set us apart in the metal istockist ndustry. We assure premier product quality and reliability. Our dedication to innovation and precision, enables us to provide to the evolving needs of our clients while maintaining the highest standards of service.
| Size | L | a | b | W | H |
|---|---|---|---|---|---|
| 1/8″ | 56 | 28 | 28 | 60 | 80 |
| ¼” | 56 | 28 | 28 | 60 | 80 |
| 3/8” | 56 | 28 | 28 | 60 | 80 |
| ½” | 58 | 28 | 28 | 60 | 81 |
| ¾” | 62 | 35 | 35 | 60 | 85 |
| 1” | 70 | 45 | 45 | 70 | 100 |
Contact us to get a quick quote for your requirement.
Venton Tube Fittings is a trusted and exporter of top-quality Stainless Steel 321 Needle Valve Philippines. Our products are used widely across diverse industries, proving our commitment to excellence and customer satisfaction. Our unique finishing processes set us apart in the metal istockist ndustry. We assure premier product quality and reliability. Our dedication to innovation and precision, enables us to provide to the evolving needs of our clients while maintaining the highest standards of service.
321 Stainless Steel Needle Valves consist of iron, chromium (17-19%), nickel (9-12%), and titanium (a minimum of five times the carbon content) to stabilize for carbide precipitation. The composition improves high-temperature operation and corrosion resistance. Its mechanical properties include tensile strength of around 515 MPa, yield strength of 205 MPa, and elongation of 40%. Physical it is 7.9 g/cm³, has a melting point of 1398-1446°C, and a very good thermal conductivity, appropriate for harsh environments.
Please feel free to contact us if you need any further information or for enquiry.
