Curtis Tube Fittings is a reputable manufacturer and supplier located in Manila, Philippines, focusing on top-notch Stainless Steel 304H Instrumentation Tube Fittings. Designed for strength, precision, and resistance to corrosion, these fittings are perfect for high-temperature and high-pressure fluid control systems. Renowned for their durability and dependable sealing, they guarantee leak-free performance even in the toughest environments. Curtis Tube Fittings provides products that adhere to international standards, serving industries like petrochemical, power generation, oil and gas, and chemical processing. Their Stainless Steel 304H Instrumentation Tube Fittings promise efficient, safe, and long-lasting service in critical instrumentation applications.
These fittings are primarily made of iron, with 18–20% chromium and 8–11% nickel, featuring a higher carbon content than 304 for enhanced high-temperature strength. They boast a tensile strength of around 515 MPa and good yield strength, offering excellent resistance to oxidation and corrosion. These fittings retain their mechanical properties even at elevated temperatures, providing outstanding toughness, weldability, and durability. With their smooth surface finish and robust structural integrity, they are well-suited for precise fluid handling in harsh operating conditions and demanding industrial systems.
| Specifications | ASTM A182, A276, A479 / ASME SA182, SA276, SA479 |
|---|---|
| Size | 1/16 in. to 2 in. & 2mm to 50 mm. |
| Dimensional Range | 1/16 to 2 inches (imperial); 2 to 50 mm (metric) |
| Working Pressures | Upto 2000 to 6000 PSI |
| Thread Type | NPT – ASME B1.20.1, SAE AS71051 | ISO/BSP Parallel – ISO 228 | ISO/BSP Tapered – ISO 7, BS EN 10226-1 | SAE (Unified) – ASME B1.1 |
| End Connections | NPT, ISO/BP, SAE/MS, AN, weld ends, port connectors, sanitary flanges, tube adapters |
| Types | Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories |
| Equivalent To | SWAGELOK, PARKER, DK-LOK, HOKE |
| Max Working Pressure | 8MPa | 1200psi Depending on The Tubing Material |
| Working Temperature | -40°C—250°C | -40°F—482°F Depending on The Tubing Material |
| Configurations | Straights, elbows, tees, crosses, caps, plugs, nuts and ferrules Chromatograph and Column End |
| Tube Fitting uses & application |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 304H | 0.10 max | 2.0 max | 0.75 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 10.5 | – |
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 304H | 515 | 205 | 40 | 92 | 201 |
Venton Tube Fittings is the premier supplier, manufacturer and exporter of Stainless Steel 304H Instrumentation Tube Fittings in Manila, Philippines. Our strategic manufacturing units placed in the Philippines allow us to supply high-quality solutions customized to your needs. We value Efficiency and Excellence. Ensuring that our products meet the highest industry standards. Maintaining a well-stocked inventory we are always ready to ship orders in time and reliably. Our dedication to customer satisfaction compels us to deliver strong and reliable solutions for a wide range of industrial uses.
| STANDARD | UNS | WERKSTOFF NR. | JIS |
| SS 304H | S30409 | 1.4948 | SUS 304H |
Contact us to get a quick quote for your requirement.
Venton Tube Fittings is a trusted and exporter of top-quality Stainless Steel 304H Instrumentation Tube Fittings Philippines. Our products are used widely across diverse industries, proving our commitment to excellence and customer satisfaction. Our unique finishing processes set us apart in the metal istockist ndustry. We assure premier product quality and reliability. Our dedication to innovation and precision, enables us to provide to the evolving needs of our clients while maintaining the highest standards of service.
Stainless Steel 304H Instrumentation Tube Fittings are extensively used in industries where reliability and high-temperature performance are crucial. They find common applications in petrochemical and chemical plants, power generation facilities, oil and gas refineries, and steam processing units. Their remarkable corrosion resistance makes them ideal for aggressive environments, while their high strength ensures secure fluid and gas transmission. These fittings are also employed in instrumentation systems, control lines, and process piping. Their ability to provide precise, leak-free connections is essential for safety, making them a trusted choice in critical applications.
Please feel free to contact us if you need any further information or for enquiry.
