We are a well-known manufacturer and supplier of Curtis tube fittings in Manila, Philippines, dealing in high-quality Stainless Steel 316 Hydraulic Fittings. These fittings are engineered for optimum performance in high-pressure hydraulic applications, providing high corrosion resistance and durability. SS 316 hydraulic fittings provide leak-proof and secure connections in fluid transfer applications. Designed to international standards, our products are used extensively in oil & gas, marine, chemical processing, and power generation industries where reliability and strength are a must.
Stainless Steel 316 Hydraulic Fittings are made up of iron, chromium (16-18%), nickel (10-14%), and molybdenum (2-3%), which makes them resistant to corrosion, particularly in environments where chlorides are present. SS 316 is mechanically of tensile strength approximately 515 MPa, yield strength 205 MPa, and elongation 40%, suitable for high-pressure use. It possesses the following physical properties: density 8.0 g/cm³, melting point 1371-1399°C, and good thermal conductivity. These characteristics render SS 316 fittings extremely resistant to harsh conditions
| DESIGN STANDARD | DIN 2353/ ISO 8434-1 |
| MATERIAL | SS 316 ,SS 316L |
| SERIES | LL- LOW PRESSURE , L- MEDIUM PRESSURE, S- HIGH PRESSURE |
| WORKING PRESSURE | (LOW) LL SERIES – 100 BAR |
| (MEDIUM)L SERIES – 100 BAR TO 500 BAR | |
| (HEAVY)S SERIES – 200 BAR TO 800 BAR | |
| SIZE RANGE | LL SERIES – 4LL TO 12LL |
| L SERIES – 6L TO 42L | |
| S SERIES – 6S TO 38S | |
| CONNECTIONS | TUBE TO TUBE , TUBE TO MALE THREAD , TUBE TO FEMALE THREAD , TUBE TO BUTT WELD , TUBE TO SOCKET WELD , TUBE TO JIC 37* , TUBE TO 24* CONE, TUBE TO SWIVEL END , TUBE TO ADJUSTBALE STANDPIPE |
| WELD NIPPLE TO MALE THREAD , WELD NIPPLE TO FEMALE THREAD , WELD NIPPLE TO BUTT WELD , WELD NIPPLE TO SOCKET WELD , WELD NIPPLE TO 24* CONE , WELD NIPPLE TO 37* JIC , WELD NIPPLE TO SWIVEL | |
| BODY TYPE | FORGED, BAR STOCK |
| SURFACE | STAINLESS STEEL – EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH |
| TEMPERATURE | STAINLESS STEEL 316 – (-60*C TO 400*C) |
| APPLICATIONS & INDUSTRIES | CONSTRUCTION EQUIPMENTS , DRILLING PLATFORMS, HYDRO POWER PLANTS , MACHINE TOOLS , RAILWAY TECHNOLOGY , SHIPBUILDING , WIND TUBRINE , MOBILE HYDRAULIC EQUIPMENT , MINNING , STATIONARY HYDRAULIC EQUIPMENT, INDUSTRIAL HYDRAULICS, INJECTION MOULDING MACHINERY , ALUMINUM DIE-CASTING MACHINERY, SINTERING MACHINERY, STEEL MILLS, HYDRAULIC PRESSES, PAPER PROCESSING MOBILE HYDRAULICS, BUILDING MACHINERY, AGRICULTURAL FORESTRY, LIFTING & MATERIAL HANDLING EQUIPMENT |
| MATERIAL DESIGNATOR | STAINLESS STEEL – ASTM A 276 , ASTM 182 |
Grade | Mn | C | S | Mo | N | Si | P | Cr | Ni | |
316 | Minimum | – | – | – | 2.00 | – | – | 0 | 16.0 | 10.0 |
Maximum | 2.0 | 0.08 | 0.03 | 3.00 | 0.10 | 0.75 | 0.045 | 18.0 | 14.0 | |
316H | Minimum | 0.04 | 0.04 | – | 2.00 | – | 0 | – | 16.0 | 10.0 |
Maximum | 0.10 | 0.10 | 0.03 | 3.00 | – | 0.75 | 0.045 | 18.0 | 14.0 |
Grade | Elong (% in 50mm) min | Yield Str 0.2% Proof (MPa) min | Tensile Str (MPa) min | Hardness | |
Rockwell B (HR B) max | Brinell (HB) max | ||||
316 | 40 | 205 | 515 | 95 | 217 |
316H | 40 | 205 | 515 | 95 | 217 |
Grade | British | Euronorm | UNS No | SS | JIS | ||
European Standards | British Standards | DIN No | Name | ||||
316 | 58H, 58J | 316S31 | 1.4401 | X5CrNiMo17-12-2 | S31600 | 2347 | SUS 316 |
316H | – | 316S51 | – | – | S31609 | – | – |
Venton Tube Fittings is the premier supplier, manufacturer and exporter of Stainless Steel 316 Hydraulic Fittings in Manila, Philippines. Our strategic manufacturing units placed in the Philippines allow us to supply high-quality solutions customized to your needs. We value Efficiency and Excellence. Ensuring that our products meet the highest industry standards. Maintaining a well-stocked inventory we are always ready to ship orders in time and reliably. Our dedication to customer satisfaction compels us to deliver strong and reliable solutions for a wide range of industrial uses.
Contact us to get a quick quote for your requirement.
Venton Tube Fittings is a trusted and exporter of top-quality Stainless Steel 316 Hydraulic Fittings Philippines. Our products are used widely across diverse industries, proving our commitment to excellence and customer satisfaction. Our unique finishing processes set us apart in the metal istockist ndustry. We assure premier product quality and reliability. Our dedication to innovation and precision, enables us to provide to the evolving needs of our clients while maintaining the highest standards of service.
SS 316 Hydraulic Fittings find extensive application in high-pressure and corrosion-resistant fluid transfer solutions needed in various industries. They are particularly crucial in offshore drilling, chemical processing, and naval applications because of their resistance to salt water and hostile chemicals. The fittings provide safe connections in hydraulic systems used in power plants, refineries, and automobile industries. Their high level of durability and leak-tight performance makes them the best for temperature and pressure extremes, providing efficient fluid flow in adverse industrial environments.
Please feel free to contact us if you need any further information or for enquiry.
