Curtis Tube Fittings is a reputable manufacturer and supplier located in Manila, Philippines, specializing in top-notch Stainless Steel 316Ti Hydraulic Fittings. These fittings are celebrated for their outstanding corrosion resistance, strength, and durability, making them perfect for high-pressure hydraulic systems and tough operating conditions. With titanium added for stabilization, they boast improved resistance to sensitization and intergranular corrosion, ensuring they perform reliably and last longer. Curtis Tube Fittings prides itself on precision engineering, quality assurance, and prompt delivery, catering to industries like petrochemical, oil and gas, power generation, and marine applications with high-performance hydraulic fitting solutions.
The Stainless Steel 316Ti Hydraulic Fittings are made up of iron, 16–18% chromium, 10–14% nickel, 2–3% molybdenum, and a touch of titanium for stabilization. They deliver a tensile strength of around 515 MPa and impressive yield strength, guaranteeing excellent mechanical stability under pressure. The titanium content not only enhances resistance to sensitization but also boosts performance at higher temperatures. These fittings are also known for their remarkable resistance to pitting, crevice corrosion, and stress cracking, making them a reliable choice for critical hydraulic systems in corrosive and demanding environments.
| DESIGN STANDARD | DIN 2353/ ISO 8434-1 |
| MATERIAL | SS 316TI ( 1.4571) |
| SERIES | LL- LOW PRESSURE , L- MEDIUM PRESSURE, S- HIGH PRESSURE |
| WORKING PRESSURE | (LOW) LL SERIES – 100 BAR |
| (MEDIUM)L SERIES – 100 BAR TO 500 BAR | |
| (HEAVY)S SERIES – 200 BAR TO 800 BAR | |
| SIZE RANGE | LL SERIES – 4LL TO 12LL |
| L SERIES – 6L TO 42L | |
| S SERIES – 6S TO 38S | |
| CONNECTIONS | TUBE TO TUBE , TUBE TO MALE THREAD , TUBE TO FEMALE THREAD , TUBE TO BUTT WELD , TUBE TO SOCKET WELD , TUBE TO JIC 37* , TUBE TO 24* CONE, TUBE TO SWIVEL END , TUBE TO ADJUSTBALE STANDPIPE |
| WELD NIPPLE TO MALE THREAD , WELD NIPPLE TO FEMALE THREAD , WELD NIPPLE TO BUTT WELD , WELD NIPPLE TO SOCKET WELD , WELD NIPPLE TO 24* CONE , WELD NIPPLE TO 37* JIC , WELD NIPPLE TO SWIVEL | |
| BODY TYPE | FORGED, BAR STOCK |
| ACCESSORIES | O-RING, DOWTY SEAL , COPPER WASHER , ED SEAL, CUTTING RING , NUT |
| O-RING & SEALS | NBR ( -35*C TO 100* C ) VITON (-25*C TO 200* C) , PTFE – (-60*C TO 240*) |
| SURFACE | STAINLESS STEEL 316 TI – EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH |
| TEMPERATURE | STAINLESS STEEL – (-60*C TO 400*C) |
| MATERIAL DESIGNATOR | STAINLESS STEEL – ASTM A 276 , ASTM 182 |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 316TI | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 10.00 – 14.00 | 68.395 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316TI | 1.4571 | S31635 | SUS 316Ti | 320S31 | 08Ch17N13M2T | Z6CNDT17‐123 | X6CrNiMoTi17-12-2 |
Venton Tube Fittings is the premier supplier, manufacturer and exporter of (Stainless Steel 316ti Hydraulic Fittings) in Manila, Philippines. Our strategic manufacturing units placed in the Philippines allow us to supply high-quality solutions customized to your needs. We value Efficiency and Excellence. Ensuring that our products meet the highest industry standards. Maintaining a well-stocked inventory we are always ready to ship orders in time and reliably. Our dedication to customer satisfaction compels us to deliver strong and reliable solutions for a wide range of industrial uses.
Contact us to get a quick quote for your requirement.
Venton Tube Fittings is a trusted and exporter of top-quality(Stainless Steel 316ti Hydraulic Fittings) Philippines. Our products are used widely across diverse industries, proving our commitment to excellence and customer satisfaction. Our unique finishing processes set us apart in the metal istockist ndustry. We assure premier product quality and reliability. Our dedication to innovation and precision, enables us to provide to the evolving needs of our clients while maintaining the highest standards of service.
You’ll find Stainless Steel 316Ti Hydraulic Fittings widely used in sectors where corrosion resistance and high-pressure strength are crucial. They’re commonly found in oil and gas refineries, petrochemical plants, marine and offshore industries, and power generation facilities. Their exceptional durability and ability to withstand aggressive environments make them perfect for hydraulic lines, fluid transfer systems, and instrumentation control. Additionally, they’re utilized in chemical processing, water treatment, and high-temperature steam applications. With their superior strength, leak-free performance, and long service life, these fittings ensure dependable operation in various applications.
