Curtis Tube Fittings is one of the top manufacturers and suppliers of adjustable locknut elbows in Manila, Philippines. With an emphasis on precision engineering and reliability, the company offers leak-proof fittings for different industrial uses. Adjustable locknut elbows have been designed to make angular adjustments in piping systems and secure the connection. These elbows are most commonly used in hydraulic, pneumatic, and fluid transfer systems in various industries including manufacturing, construction, automotive, and aerospace for effective and adjustable fluid flow management.

45 Degree Hydraulic Adjustable Elbow Supplier in Manila, 45 Degree Swivel Elbow Price List in Cebu City, C.s Adjustable Elbow Stand Pipe Manufacturer in Davao City, Din Swivel Elbow In Baguio, Male Jic X Female Swivel Elbow Exporter in Cebu City, Ss Swivel Adjustable Elbow Manufacturer in Puerto Princesa, Cs Swive Elbow In Manila, Philippines.

Adjustable Locknut Elbow Specifications
Top Adjustable Locknut Elbow Manufacturing Company in Manila
Types of Adjustable Locknut Elbow
Adjustable Locknut Elbow Technical Data
Largest Adjustable Locknut Elbow Supplier in Manila, Philippines
Adjustable Locknut Elbow Uses
Visit Our Other Products

Adjustable locknut elbows are generally constructed from high-strength materials like stainless steel, carbon steel, brass, or aluminum, providing excellent corrosion resistance and durability. They possess excellent tensile strength mechanically, have better pressure-holding performance, and endure vibrations and mechanical loading. The physical characteristics that their fittings encompass involve a free-surface condition that ensures full flow of fluids internally, with high precision-locknuts for keeping position, along with high heat and chemical resistances. With guaranteed performance over rugged conditions with leak prevention, making adjustments very convenient to different orientations of application, their application cannot be rivaled.

Adjustable Locknut Elbow Specifications

STANDARD	DIN 2353/ ISO 8434-1
MATERIAL	MS, CS, SS 304, SS 304L, SS 316, SS 316L, SS 316TI ( 1.4571), BRASS, COPPER, DUPLEX, SUPER DUPLEX, INCONEL, MONEL, HASTELLOY, 904L, 6MO, TITANIUM, ALUMINUM, ALLOY 20
MATERIAL
SERIES	LL- LOW PRESSURE, L- MEDIUM PRESSURE, S- HIGH PRESSURE
WORKING PRESSURE	(LOW) LL SERIES – 100 BAR
	(MEDIUM)L SERIES – 100 BAR TO 500 BAR
	(HEAVY)S SERIES – 200 BAR TO 800 BAR
SIZE RANGE	LL SERIES – 4LL TO 12LL
	L SERIES – 6L TO 42L
	S SERIES – 6S TO 38S
BODY TYPE	FORGED, BAR STOCK
ACCESSORIES	O-RING, DOWTY SEAL, COPPER WASHER, ED SEAL, CUTTING RING, NUT
O-RING & SEALS	NBR ( -35C TO 100 C ) VITON (-25C TO 200 C) , PTFE – (-60C TO 240)
SURFACE	CARBON STEEL -TRIVALENT ZINC PLATED, YELLOW PLATTING, BLACK PHOSPHATE,
SURFACE	STAINLESS STEEL – EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH
TEMPERATURE	STEEL – (-40* C TO 120C) ,STAINLESS STEEL – (-60C TO 400C) BRASS – (-60C TO 175*C)

Top Adjustable Locknut Elbow Manufacturing Company in Manila

Venton Tube Fittings is the premier supplier, manufacturer and exporter of Adjustable Locknut Elbow in Manila, Philippines. Our strategic manufacturing units placed in the Philippines allow us to supply high-quality solutions customized to your needs. We value Efficiency and Excellence. Ensuring that our products meet the highest industry standards. Maintaining a well-stocked inventory we are always ready to ship orders in time and reliably. Our dedication to customer satisfaction compels us to deliver strong and reliable solutions for a wide range of industrial uses.

Types of Adjustable Locknut Elbow

Adjustable Locknut Elbow Technical Data

Series	Tube ?D1	F1	F	L	A	L1	P
L	6	14	12	27	12	26	M 12 x 1.5
light	8	17	12	29	14	27.5	M 14 x 1.5
PN 315	10	19	14	30	15	29	M 16 x 1.5
	12	22	17	32	17	29.5	M 18 x 1.5
	15	27	19	36	21	32.5	M 22 x 1.5
	18	32	24	40	23.5	35.5	M 26 x 1.5
PN 160	22	36	27	44	27.5	38.5	M 30 x 2
	28	41	36	47	30.5	41.5	M 36 x 2
	35	50	41	56	34.5	51	M 45 x 2
	42	60	50	63	40	56	M 52 x 2
S	6	17	12	31	16	27	M 14 x 1.5
heavy	8	19	14	32	17	27.5	M 16 x 1.5
PN 630	10	22	17	34	17.5	30	M 18 x 1.5
	12	24	17	38	21.5	31	M 20 x 1,5
	14	27	19	40	22	35	M 22 x 1.5
PN 400	16	30	24	43	24.5	36.5	M 24 x 1.5
	20	36	27	48	26.5	44.5	M 30 x 2
	25	36	36	54	30	50	M 36 x 2
	30	50	41	62	35.5	55	M 42 x 2
PN 315	38	60	50	72	41	63	M 52 x 2

45 Degree Hydraulic Adjustable Elbow Exporter in Manila, C.s Adjustable Elbow Stand Pipe Price List in Cebu City, 45 Degree Swivel Elbow Manufacturer in Davao City, Din Swivel Elbow In Baguio, Male Jic X Female Swivel Elbow Supplier in Cebu City, Ss Swivel Adjustable Elbow Manufacturer in Puerto Princesa, Cs Swive Elbow In Manila, Philippines.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Adjustable Locknut Elbow Supplier in Manila, Philippines

Venton Tube Fittings is a trusted and exporter of top-quality Adjustable Locknut Elbow Philippines. Our products are used widely across diverse industries, proving our commitment to excellence and customer satisfaction. Our unique finishing processes set us apart in the metal istockist ndustry. We assure premier product quality and reliability. Our dedication to innovation and precision, enables us to provide to the evolving needs of our clients while maintaining the highest standards of service.

Adjustable Locknut Elbow Uses

Adjustable locknut elbows are used extensively in hydraulic and pneumatic networks for guiding fluid flow at accurate angles with a firm connection. They are used in manufacturing and construction for piping flexibility, enhancing system efficiency. Automotive and aerospace applications utilize them in fuel, cooling, and lubrication systems for consistent performance under high pressure and temperature fluctuations. Also, they find applications in chemical processing, oil and gas, and water treatment facilities, where the fittings need to be strong and resistant to corrosion for secure and effective fluid transfer.
