Curtis Tube Fittings, located in Manila, Philippines, stands out as a top manufacturer and supplier of high-quality Hydraulic Male Stud Couplings. Renowned for their precision engineering, durability, and leak-proof performance, these couplings are crafted to ensure secure and dependable connections in high-pressure hydraulic systems. Curtis takes pride in guaranteeing that each Hydraulic Male Stud Coupling adheres to international standards, providing mechanical strength, operational reliability, and a long service life. Catering to the oil and gas, chemical, marine, and industrial sectors, Curtis delivers robust solutions that prioritize operational safety, efficiency, and consistent performance in challenging hydraulic applications.
These Hydraulic Male Stud Couplings are made from premium stainless steel or alloy materials, which offer outstanding tensile strength, toughness, and resistance to corrosion. They are designed to endure high-pressure hydraulic fluids and repeated connection cycles without any leakage or failure. With their precision threading, they ensure a secure fit with female fittings, maintaining system integrity and reducing maintenance needs, even in tough operating conditions.
| STANDARD | DIN 2353/ ISO 8434-1 |
| MATERIAL | MS, CS, SS 304 ,SS 304L , SS 316 ,SS 316L, SS 316TI ( 1.4571) , BRASS , COPPER , DUPLEX , SUPER DUPLEX , INCONEL , MONEL , HASTELLOY , 904L , 6MO, TITANIUM , ALUMNIUM, ALLOY 20 |
| SERIES | LL- LOW PRESSURE , L- MEDIUM PRESSURE, S- HIGH PRESSURE |
| WORKING PRESSURE | (LOW) LL SERIES – 100 BAR |
| (MEDIUM)L SERIES – 100 BAR TO 500 BAR | |
| (HEAVY)S SERIES – 200 BAR TO 800 BAR | |
| SIZE RANGE | LL SERIES – 4LL TO 12LL |
| L SERIES – 6L TO 42L | |
| S SERIES – 6S TO 38S | |
| CONNECTIONS | TUBE TO MALE THREAD , WELD NIPPLE TO MALE THREAD |
| BODY TYPE | BAR STOCK |
| ACCESSORIES | O-RING, DOWTY SEAL , COPPER WASHER , ED SEAL, CUTTING RING , NUT |
| O-RING & SEALS | NBR ( -35*C TO 100* C ) VITON (-25*C TO 200* C) , PTFE – (-60*C TO 240*) |
| SURFACE | CARBON STEEL -TRIVALENT ZINC PLATED , YELLOW PLATTING , BLACK PHOSPHATED, |
| STAINLESS STEEL – EXPORT BRIGHT FINISH, SHORT BLASTED FINISH | |
| TEMPERATURE | STEEL – (-40* C TO 120*C) ,STAINLESS STEEL – (-60*C TO 400*C) BRASS – (-60*C TO 175*C) |
| APPLICATIONS & INDUSTRIES | CONSTRUCTION EQUIPMENTS , DRILLING PLATFORMS, HYDRO POWER PLANTS , MACHINE TOOLS , RAILWAY TECHNOLOGY , SHIPBUILDING , WIND TUBRINE , MOBILE HYDRAULIC EQUIPMENT , MINNING , STATIONARY HYDRAULIC EQUIPMENT, INDUSTRIAL HYDRAULICS, INJECTION MOULDING MACHINERY , ALUMINUM DIE-CASTING MACHINERY, SINTERING MACHINERY, STEEL MILLS, HYDRAULIC PRESSES, PAPER PROCESSING MOBILE HYDRAULICS, BUILDING MACHINERY, AGRICULTURAL FORESTRY, LIFTING & MATERIAL HANDLING EQUIPMENT |
| MATERIAL DESIGNATOR | STAINLESS STEEL – ASTM A 276 , ASTM 182 |
| STEEL – ASTM 108/A105, JIS G4051 S20C, S45C,/G3201 SF440A. | |
| BRASS – ASTM B16 UNS C36000 , ASTM B282 ALLOY 37700 , JIS H3250 C3604 , C3771 , JIS H3250 C3771. |
Venton Tube Fittings is the premier supplier, manufacturer and exporter of (Hydraulic Male Stud Coupling) in Manila, Philippines. Our strategic manufacturing units placed in the Philippines allow us to supply high-quality solutions customized to your needs. We value Efficiency and Excellence. Ensuring that our products meet the highest industry standards. Maintaining a well-stocked inventory we are always ready to ship orders in time and reliably. Our dedication to customer satisfaction compels us to deliver strong and reliable solutions for a wide range of industrial uses.
| DIAM D | C | E | F | F1 | DIM G | H | HMAXI | H1 | BODY | SEALING WASHER | MINIMUM WORKING TEMPERATURE | MAXIMUM WORKING TEMPERATURE |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4 MM | G1/8 | 6,5 MM | 13 MM | 10 MM | 16,5 MM | 8 MM | brass | nitrile | -40 CE | 100 CE | 0,015 KG | 10 |
| 4 MM | G1/8 | 5,5 MM | 13 MM | 10 MM | 14 MM | 17,5 MM | 9 MM | brass | nitrile | -40 CE | 100 CE | 0,016 KG |
| 4 MM | M5x0,8 | 5 MM | 10 MM | 10 MM | 16,5 MM | 8 MM | brass | nitrile | -40 CE | 100 CE | 0,01 KG | 10 |
| 4 MM | M7x1 | 6,5 MM | 10 MM | 10 MM | 16,5 MM | 7,5 MM | brass | nitrile | -40 CE | 100 CE | 0,013 KG | 10 |
| 4 MM | M8x1 | 6,5 MM | 11 MM | 10 MM | 16,5 MM | 7,5 MM | brass | nitrile | -40 CE | 100 CE | 0,013 KG | 10 |
| 5 MM | G1/8 | 6,5 MM | 13 MM | 12 MM | 17,5 MM | 8,5 MM | brass | nitrile | -40 CE | 100 CE | 0,018 KG | 10 |
| 5 MM | G1/8 | 5,5 MM | 13 MM | 12 MM | 14 MM | 18,5 MM | 9,5 MM | brass | nitrile | -40 CE | 100 CE | 0,027 KG |
| 5 MM | M8x1 | 6,5 MM | 11 MM | 12 MM | 17,5 MM | 8 MM | brass | nitrile | -40 CE | 100 CE | 0,015 KG | 10 |
| 5 MM | M10x1 | 6,5 MM | 14 MM | 12 MM | 17,5 MM | 8,5 MM | brass | nitrile | -40 CE | 100 CE | 0,02 KG | 10 |
| 6 MM | G1/8 | 6,5 MM | 13 MM | 13 MM | 18 MM | 8,5 MM | brass | nitrile | -40 CE | 100 CE |
Contact us to get a quick quote for your requirement.
You’ll find Hydraulic Male Stud Couplings widely utilized in hydraulic systems across industrial machinery, oil and gas platforms, chemical plants, and marine applications, where they connect hoses, tubes, and pipelines. They are perfect for high-pressure fluid transfer, instrumentation lines, and process control systems, where leak-tight performance, mechanical reliability, and safety are paramount. Their exceptional durability, corrosion resistance, and precision guarantee safe, efficient, and long-lasting operation in demanding hydraulic systems.
Please feel free to contact us if you need any further information or for enquiry.
