Curtis Tube Fittings, located in Manila, Philippines, has built a solid reputation as a reliable manufacturer and supplier of top-notch Hydraulic Female Stud Couplings. Renowned for their precision engineering, durability, and leak-proof performance, these couplings are specifically designed for high-pressure hydraulic systems in demanding industrial settings. Curtis takes pride in ensuring that every Hydraulic Female Stud Coupling adheres to international standards, delivering dependable connections, mechanical strength, and a long service life. Catering to the oil and gas, chemical, marine, and industrial sectors, Curtis provides robust solutions that prioritize operational safety, efficiency, and consistent performance, even in tough hydraulic conditions.
These Hydraulic Female Stud Couplings are crafted from high-quality stainless steel or alloy materials, which offer remarkable tensile strength, toughness, and resistance to corrosion. They are engineered to handle high-pressure hydraulic fluids and endure repeated connection cycles without any leaks or failures. With their precision threading, they guarantee a secure and reliable fit with male studs, ensuring system integrity and reducing maintenance needs, even in harsh operating environments.
| STANDARD | DIN 2353/ ISO 8434-1 |
| MATERIAL | MS, CS, SS 304 ,SS 304L , SS 316 ,SS 316L, SS 316TI ( 1.4571) , BRASS , COPPER , DUPLEX , SUPER DUPLEX , INCONEL , MONEL , HASTELLOY , 904L , 6MO, TITANIUM , ALUMNIUM, ALLOY 20 |
| SERIES | LL- LOW PRESSURE , L- MEDIUM PRESSURE, S- HIGH PRESSURE |
| WORKING PRESSURE | (LOW) LL SERIES – 100 BAR |
| (MEDIUM)L SERIES – 100 BAR TO 500 BAR | |
| (HEAVY)S SERIES – 200 BAR TO 800 BAR | |
| SIZE RANGE | LL SERIES – 4LL TO 12LL |
| L SERIES – 6L TO 42L | |
| S SERIES – 6S TO 38S | |
| CONNECTIONS | TUBE TO FEMALE THREAD, WELD NIPPLE TO FEMALE THREAD |
| BODY TYPE | BAR STOCK |
| SURFACE | CARBON STEEL -TRIVALENT ZINC PLATED , YELLOW PLATTING , BLACK PHOSPHATED, |
| STAINLESS STEEL – EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH | |
| TEMPERATURE | STEEL – (-40* C TO 120*C) ,STAINLESS STEEL – (-60*C TO 400*C) BRASS – (-60*C TO 175*C) |
| APPLICATIONS & INDUSTRIES | CONSTRUCTION EQUIPMENTS , DRILLING PLATFORMS, HYDRO POWER PLANTS , MACHINE TOOLS , RAILWAY TECHNOLOGY , SHIPBUILDING , WIND TUBRINE , MOBILE HYDRAULIC EQUIPMENT , MINNING , STATIONARY HYDRAULIC EQUIPMENT, INDUSTRIAL HYDRAULICS, INJECTION MOULDING MACHINERY , ALUMINUM DIE-CASTING MACHINERY, SINTERING MACHINERY, STEEL MILLS, HYDRAULIC PRESSES, PAPER PROCESSING MOBILE HYDRAULICS, BUILDING MACHINERY, AGRICULTURAL FORESTRY, LIFTING & MATERIAL HANDLING EQUIPMENT |
| MATERIAL DESIGNATOR | STAINLESS STEEL – ASTM A 276 , ASTM 182 |
| STEEL – ASTM 108/A105, JIS G4051 S20C, S45C,/G3201 SF440A. | |
| BRASS – ASTM B16 UNS C36000 , ASTM B282 ALLOY 37700 , JIS H3250 C3604 , C3771 , JIS H3250 C3771. |
Venton Tube Fittings is the premier supplier, manufacturer and exporter of Hydraulic Female Stud Coupling in Manila, Philippines. Our strategic manufacturing units placed in the Philippines allow us to supply high-quality solutions customized to your needs. We value Efficiency and Excellence. Ensuring that our products meet the highest industry standards. Maintaining a well-stocked inventory we are always ready to ship orders in time and reliably. Our dedication to customer satisfaction compels us to deliver strong and reliable solutions for a wide range of industrial uses.
| Tube O/D (mm) | Series | BSPP Female Thread | Pressure bar |
|---|---|---|---|
| 6 | L | G 1/8 | PN 315 |
| 6 | L | G 1/4 | PN 315 |
| 6 | L | G 3/8 | PN 315 |
| 8 | L | G 1/4 | PN 315 |
| 8 | L | G 3/8 | PN 315 |
| 8 | L | G 1/2 | PN 315 |
| 10 | L | G 1/4 | PN 315 |
| 10 | L | G 3/8 | PN 315 |
| 10 | L | G 1/2 | PN 315 |
| 12 | L | G 1/4 | PN 315 |
| 12 | L | G 3/8 | PN 315 |
| 12 | L | G 1/2 | PN 315 |
| 15 | L | G 3/8 | PN 315 |
| 15 | L | G 1/2 | PN 315 |
| 18 | L | G 1/2 | PN 315 |
| 22 | L | G 3/4 | PN 160 |
| 28 | L | G 1 | PN 160 |
| 35 | L | G 1 1/4 | PN 160 |
| 42 | L | G 1 1/2 | PN 160 |
| 6 | S | G 1/4 | PB 630 |
| 8 | S | G 1/4 | PB 630 |
| 10 | S | G 3/8 | PB 630 |
| 12 | S | G 3/8 | PB 630 |
| 12 | S | G 1/2 | PB 630 |
| 14 | S | G 1/2 | PB 630 |
| 16 | S | G 1/2 | PB 400 |
| 20 | S | G 3/4 | PB 400 |
| 25 | S | G 1 | PB 400 |
| 30 | S | G 1 1/4 | PB 400 |
| 38 | S | G 1 1/2 | PB 315 |
Contact us to get a quick quote for your requirement.
You’ll find Hydraulic Female Stud Couplings widely utilized in hydraulic systems across oil and gas platforms, industrial machinery, marine equipment, and chemical processing plants. They’re perfect for connecting hoses, tubes, and pipelines in high-pressure fluid transfer applications. Moreover, they play a crucial role in instrumentation and process control systems where leak-tight performance, mechanical reliability, and safety are paramount. Their outstanding durability and corrosion resistance make them a safe, efficient, and long-lasting choice for demanding hydraulic systems.
Hydraulic female stud couplings are essential components in hydraulic systems, commonly used to connect hoses and pipes securely. They enable quick and efficient fluid transfer in various applications, including construction, agriculture, and manufacturing. These couplings provide leak-free connections, ensuring system efficiency and safety under high-pressure conditions. They are also vital in hydraulic machinery, such as excavators and loaders, facilitating easy assembly and disassembly for maintenance. Additionally, their robust design ensures durability, making them suitable for harsh operating environments.
Please feel free to contact us if you need any further information or for enquiry.
