Curtis Tube Fittings, located in Manila, Philippines, has earned a solid reputation as a reliable manufacturer and supplier of top-notch Hydraulic Banjo Elbow fittings. These fittings are specifically designed for efficient fluid transfer in high-pressure hydraulic systems. Known for their precision engineering, exceptional durability, and adherence to international standards, Curtis Tube Fittings caters to a diverse array of industries, including construction, oil and gas, marine, and manufacturing. Each Hydraulic Banjo Elbow is crafted to guarantee leak-free performance, easy installation, and a long lifespan. Thanks to advanced production methods and rigorous quality control, Curtis ensures that their fittings boost system reliability, safety, and efficiency, even in the toughest conditions.
Typically, Hydraulic Banjo Elbow fittings are made from robust and corrosion-resistant materials like carbon steel, stainless steel (304 and 316), and brass. These materials are selected for their impressive mechanical strength, pressure resistance, and durability against hydraulic fluids. The fittings boast high tensile strength, hardness, and fatigue resistance, ensuring they perform reliably in high-pressure and high-temperature situations. Their elbow design optimizes fluid flow direction, while the banjo bolt connection creates a secure, sealed joint with a full 360-degree fluid pathway. Precision machining guarantees smooth internal surfaces, which help reduce pressure drops and improve overall hydraulic efficiency.
Venton Tube Fittings is the premier supplier, manufacturer and exporter of (Hydraulic Banjo Elbow) in Manila, Philippines. Our strategic manufacturing units placed in the Philippines allow us to supply high-quality solutions customized to your needs. We value Efficiency and Excellence. Ensuring that our products meet the highest industry standards. Maintaining a well-stocked inventory we are always ready to ship orders in time and reliably. Our dedication to customer satisfaction compels us to deliver strong and reliable solutions for a wide range of industrial uses.
| Pressure | Pipe Diameter | Thread |
| L Series | ||
| 100 | 4 | G 1/8″ |
| 100 | 6 | G 1/8″ |
| 100 | 8 | G 1/8″ |
| 500 | 6 | G 1/8″ |
| 400 | 8 | G 1/4″ |
| 350 | 10 | G 1/4″ |
| 350 | 10 | G 3/8″ |
| 350 | 12 | G 1/4″ |
| 350 | 12 | G 3/8″ |
| 315 | 12 | G 1/2″ |
| 315 | 15 | G 1/2″ |
| 315 | 18 | G 1/2″ |
| 200 | 22 | G 3/4″ |
| 200 | 28 | G 1″ |
| 200 | 35 | G 1 1/4″ |
| 200 | 42 | G 1 1/2″ |
| S Series | ||
| 500 | 6 | G 1/4″ |
| 450 | 8 | G 1/4″ |
| 400 | 10 | G 1/4″ |
| 400 | 10 | G 3/8″ |
| 400 | 12 | G 3/8″ |
| 400 | 14 | G 1/2″ |
| 400 | 16 | G 1/2″ |
| 400 | 20 | G 3/4″ |
| 250 | 25 | G 1″ |
| 250 | 30 | G 1 1/4″ |
| 250 | 38 | G 1 1/2″ |
Contact us to get a quick quote for your requirement.
These fittings are particularly popular in hydraulic systems where space is tight and a change in fluid flow direction is necessary. They’re perfect for automotive brake and fuel systems, heavy machinery, hydraulic equipment, and industrial power units. Hydraulic Banjo Elbow fittings facilitate fluid transfer through a hollow bolt and spherical union, offering flexibility and compactness without sacrificing strength. Their design simplifies maintenance and assembly while preventing leaks under high pressure. In short, Hydraulic Banjo Elbows are vital for applications that demand reliability and efficiency.
Banjo Elbows Hydraulic are most commonly used in the automotive, industrial machinery, and hydraulic systems that require compact space and angle fluid transfer. These fittings are perfect for engine applications, power steering systems, and construction equipment, where there are limited or constricted areas that need a sure connection. They are known to offer high-performance sealing and fluid flow, which guarantees efficiency and longevity under high pressure. The banjo elbow design facilitates flexible mounting in multiple configurations without compromising the integrity of the hydraulic system.
Please feel free to contact us if you need any further information or for enquiry.
